À propos du produit
Internal hard drives with higher capacities and lower TCO
Data center decisions are driven by TCO. The Ultrastar DC HC550, with 14TB, 16TB & 18TB, play a leading role in reducing TCO.
Total Cost of Ownership (TCO) Drives the Data Center Architecture
Data center decisions are driven by TCO. Higher capacity hard drives play a leading role in reducing TCO. An 18TB data center internal hard drive provides 29% more capacity in the same form factor as a 14TB HDD. Higher capacity HDDs enable data centers to lower CapEx by reducing supporting hardware and system level costs when compared to lower capacity drives. Helium-sealed, low power, high reliability drives reduce energy and maintenance costs, contributing to OpEx savings. For example, a data center using 18TB HDDs vs. 14TB HDDs can require 22% fewer racks while consuming 21% less power per TB at idle, resulting in significant overall TCO reduction for data center environments.
Raising the Capacity Bar with New Technologies
Ultrastar DC HC550 integrates a suite of technologies on a 9-disk platform to create a new class of HDDs. 18TB capacity is achieved by combining technologies that improve areal density working together with technologies that improve performance and reduce power consumption.
? The first internal hard drives in the industry to harness Energy-Assisted Magnetic Recording (EAMR) technology improves writability and therefore increases areal density.
? The industry's first Triple Stage Actuator (TSA) enhances head-positioning accuracy, delivering better performance and increased areal density.
? HelioSeal® technology is the foundation for Western Digital's high capacity HDDs and this is the 6th generation of HelioSeal product. Western Digital has shipped >65 million HelioSeal products to date.
- Experience rapid processing speed with 512 MB cache buffer
- 12Gb/s SAS interface for high speed and reliability
- With 14 TB capacity you have ample space for storing millions of images, hundreds of hours of video or for music lovers, up to a million songs
Spécifications techniques
| Drive Performance | |
| Buffer | 512 MB |
| Spindle Speed (rpm) | 7200 |
| Interfaces/Ports | |
| Drive Interface | SAS |
| Drive Interface Standard | 12Gb/s SAS |
| Miscellaneous | |
| Operating System Compatibility | Linux |
| Windows | |
| TCO Certified | Yes |
| Technical Information | |
| Storage Capacity | 14 TB |
| Platform Supported | Linux |
| Disk Format | 512e/4Kn |
| Recording Technology | Conventional Magnetic Recording (CMR) |
| Physical Characteristics | |
| Weight (Approximate) | 1.52 lb (690 g) |
| Drive Type | Internal |
| Form Factor | 3.5" |
| Length | 5.79" (147.07 mm) |
| Height | 1.03" (26.16 mm) |
| Width | 4" (101.60 mm) |
| General Information | |
| Product Type | Hard Drive |
| Manufacturer Part Number | 0F38528 |
| Manufacturer Website Address | http://www.westerndigital.com |
| Manufacturer | Western Digital Corporation |
| Product Model | WUH721814AL5204 |
| Product Name | Ultrastar DC HC550 WUH721814AL5204 Hard Drive |
| Product Line | Ultrastar |
| Product Series | DC HC550 |
| Brand Name | Western Digital |
