À propos du produit
The TX6™ Cat 6 U/UTP copper cable is constructed of 24 AWG copper conductors with FEP/HDPE insulation. The copper conductors are twisted in pairs. All four pairs are surrounded by a PVC flame-retardant jacket. The orange, plenum (CMP) cable is supplied 1,000 feet (305 meters) to an easy pay-out carton.
- Third party tested: Cable has been tested as part of the Category 6 U/UTP Copper Cabling System by an independent laboratory and complies with the electrical channel requirements of the following Standard: ANSI/TIA-568.2-D Category 6
- Guaranteed channel performance above the Standards: Industry leading guaranteed channel performance exceeding the TIA/ISO Standards with headroom guaranteed
- Descending length cable markings: Easy identification of remaining cable reduces installation time and cable scrap
- Tested beyond the Standards: Cable has been characterized to 550 MHz, 300 MHz above the Standard
- Reelex™ packaging: Compact carton ensures proper performance and provides quick installation
Spécifications techniques
| Miscellaneous | |
| Country of Origin | United States |
| General Information | |
| Product Type | Network Cable |
| Manufacturer Part Number | PUP6C04ORWZ |
| Manufacturer Website Address | http://www.panduit.com |
| Manufacturer | PANDUIT CORP |
| Product Name | Copper Cable, Cat 6, 24 AWG, UTP, CMP, Orange |
| Product Line | TX6 |
| Brand Name | PanNet |
| Physical Characteristics | |
| Material Details |
|
| Insulation Material | High-density Polyethylene (HDPE) |
| Fluorinated Ethylene Propylene (FEP) | |
| Polyolefin | |
| Jacket Material | Fire Resistant Polyvinyl Chloride (FR-PVC) |
| Fluorinated Ethylene Propylene (FEP) | |
| Product Color | Orange |
| Product Material | Copper |
| Technical Information | |
| Cable Length | 1000.7 ft |
| Data Transfer Rate | 10 Gbit/s |
| Device Supported | Network Device |
| Jacket Type | CMP |
| Plenum | |
| Shielding | No |
| Features | Unshielded Twisted Pair (UTP) |
| Bendable | |
| Flexible | |
| PoE | |
| Flame Retardant | |
| Number of Conductors | 8 |
| Cable Type | Category 6 |
| Connector Type on First End | Bare Wire |
| Connector Type on Second End | Bare Wire |
| American Wire Gauge | 24 AWG |
| Number of Pairs | 4 |
