À propos du produit
- Enterprise-class connectivity with support for ACLs, robust QoS, and common protocols such as static and Access OSPF routing.
- Scalability with 8 member VSF stacking. 24 and 48-port fixed and modular switch models can stack together for up to 384 ports.
- Models include modular switches with 1/10GbE uplinks, LRM, and MACSec 256, fixed switches with either 1/10GbE SFP+ or 1GbE SFP uplinks, and options that support 30W to 60W of PoE per port.
- Intelligent monitoring and visibility via Aruba Network Analytics Engine. Aruba NetEdit support for automation, configuration and verification. One touch deployment using the Aruba CX Mobile App.
- Aruba Dynamic Segmentation enables enhanced security and simple access for users and IoT.
- Flexible, modular switch models support hot-swappable, redundant power supplies and fans for enhanced resiliency.
- Optimize the performance of business networks with 10 Gigabit Ethernet connectivity
- Managed switch provides a reliable foundation for your network
- Management capability provides control over setup and configuration of your network
- Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
- Built-in power supply to ensure all components are being supplied with accurate voltage
- Stack port provides an easy and hassle-free way to extend your office network
- Quickly and easily set up a wired network with 48 networking ports
- Cascade to other network devices through the uplink port to expand your local area network
Spécifications techniques
| Management & Protocols | |
| Manageable | Yes |
| Technical Information | |
| Features | Hot-swappable |
| Network & Communication | |
| Networking Standards | IEEE 802.3at |
| IEEE 802.3af | |
| I/O Expansions | |
| Expansion Slot Type | SFP+ |
| SFP | |
| Number of SFP+ Slots | 4 |
| Shared SFP Slot | Yes |
| Total Number of Expansion Slots | 4 |
| General Information | |
| Product Type | Ethernet Switch |
| Manufacturer Part Number | JL727B#B2B |
| Manufacturer Website Address | http://www.hpe.com |
| Manufacturer | Hewlett Packard Enterprise |
| Product Name | CX 6200 Ethernet Switch |
| Product Series | CX 6200 |
| Brand Name | Aruba |
| Miscellaneous | |
| Application/Usage | Branch Office |
| Network | |
| Wireless Access Point | |
| IoT Devices | |
| Enterprise | |
| Campus | |
| Data Center | |
| Physical Characteristics | |
| Weight (Approximate) | 11.24 lb (5100 g) |
| Form Factor | Rack-mountable |
| Height | 1.73" (43.94 mm) |
| Width | 17.40" (441.96 mm) |
| Depth | 12.90" (327.66 mm) |
| Compatible Rack Unit | 1U |
| Product Material | Sheet Metal |
| Media & Performance | |
| Network Technology | 1000Base-X |
| 10GBase-X | |
| 10/100/1000Base-T | |
| Maximum Data Transfer Rate | 1.25 GB/s |
| Ethernet Technology | 10 Gigabit Ethernet |
| Gigabit Ethernet | |
| Media Type Supported | Optical Fiber |
| Twisted Pair | |
| Power Description | |
| Input Voltage | 120 V AC |
| 230 V AC | |
| Power Source | AC |
| Power Supply | |
| Power Consumption | 76 W |
| Number of Power Supplies Installed | 1 |
| PoE (RJ-45) Port | Yes |
| Redundant Power Supply Supported | Yes |
| PoE Budget | 370 W |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Modular | Yes |
| Uplink Port | Yes |
| Stack Port | Yes |
| Total Number of Network Ports | 48 |
| Port/Expansion Slot Details | 1 x OOBM Port |
| 1 x RJ-45 Console Port | |
| 1 x USB Type-A Host Port | |
| 48 x 10/100/1000BASE-T Gigabit Ethernet PoE+ RJ-45 Network Port | |
| 4 x 1/10 Gigabit Ethernet SFP Expansion Slot | |
| 1 x USB-C Console Port |
