À propos du produit
- 22 MB of L3 cache to boost the instruction processing and system performance
- 14 nm enables improved performance per watt and micro architecture makes it power-efficient
- The processor upgrade features Socket P LGA-3647 socket for installation on the PCB
Spécifications techniques
| Environmental Conditions | |
| Thermal Specification | 185°F (85°C) |
| Miscellaneous | |
| Compatibility | Lenovo ThinkSystem SR570 Server |
| Power Description | |
| Thermal Design Power | 150 W |
| Physical Characteristics | |
| Width | 2.99" (76 mm) |
| Depth | 2.22" (56.50 mm) |
| General Information | |
| Product Type | Processor Upgrade |
| Manufacturer Part Number | 4XG7A37888 |
| Manufacturer Website Address | http://www.lenovo.com |
| Manufacturer | Lenovo Group Limited |
| Product Model | 6242 |
| Product Name | Xeon Gold Hexadeca-core 6242 2.80 GHz Server Processor Upgrade |
| Product Line | Xeon Gold |
| Brand Name | Lenovo |
| Technical Information | |
| Process Technology | 14 nm |
| Clock Speed | 2.80 GHz |
| Processor Socket | Socket P LGA-3647 |
| L3 Cache | 22 MB |
| Processor Core | Hexadeca-core (16 Core) |
| 64-bit Processing | Yes |
| Processor Manufacturer | Intel |
| Overclocking Speed | 3.90 GHz |
| Processor Generation | 2nd Gen |
| Processor Threads | 32 |
