À propos du produit
Installed in a high density Perle Media Converter Chassis, Perle's feature rich CM-1000MM Gigabit Fiber to Fiber Managed Media Converter Modules enable transparent fiber extension of 1000Base-SX multimode fiber to 1000Base-SX multimode or 1000Base-LX/EX/ZX/BX single mode fiber.
Perle's advanced features make the end to end fiber link completely transparent. This allows for more efficient troubleshooting and less on-site maintenance. When used with a Media Converter Management Module in the chassis, configuration and monitoring of the fiber ports can be performed. In addition, a lifetime warranty and free worldwide technical support make Perle's CM-1000MM Gigabit Fiber to Fiber Managed Media Converter Modules the smart choice for IT professionals.
- Attach multiple devices together or expand the number of devices connected to your existing network by using 2 transceiver/media converter
- With 1000Base-LX technology get up to 1000Mbps data transfer rate over optical fiber cable
- Takes minimal energy and effort to get installed internally
- With Optical Fiber cable, get the desired data transfer rate up to a required distance
Spécifications techniques
| Network & Communication | |
| Network Technology | 1000Base-LX |
| 1000Base-SX | |
| Physical Characteristics | |
| Weight (Approximate) | 149.7 g |
| Form Factor | Internal |
| Media & Performance | |
| Maximum Distance Supported | 2 km |
| Media Type Supported | Optical Fiber |
| Fiber Mode Supported | Multi-mode |
| Fiber Optic Cable Core/Cladding Specification | 50/125 µm |
| 62.5/125 µm | |
| General Information | |
| Product Type | Transceiver/Media Converter |
| Manufacturer Part Number | 05062490 |
| Manufacturer Website Address | http://www.perle.com |
| Manufacturer | Perle Systems, Inc |
| Product Model | CM-1000MM-M2ST2 |
| Product Name | CM-1000MM-M2ST2 - Gigabit Ethernet Fiber to Fiber Media Converter Managed Module |
| Brand Name | Perle |
| Miscellaneous | |
| Compatibility | Perle Media Converter Chassis |
| Certifications & Standards |
Emissions:
Electrical Safety:
Laser Safety:
Others:
|
| Country of Origin | Canada |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) | |
| Waste Electrical and Electronic Equipment Directive (WEEE) | |
| Interfaces/Ports | |
| USB | No |
| DVI | No |
| Parallel Port | No |
| Management Port | No |
| Digital Audio | No |
| Number of ST Ports | 2 |
| Digital Audio/Video | No |
| Total Number of Ports | 2 |
| ST Port Type | Duplex |
