À propos du produit
Perle Industrial-grade Ethernet Switches are designed to stand up to extreme temperatures, surges, vibrations, and shocks found in industrial automation, government, military, oil and gas, mining and outdoor applications.
In addition, these PoE Switches are classified as Power Sourcing Equipment (PSE). While using standard UTP cables that carry Ethernet data, the IDS-108FPP have 4 ports that also provide up to 30 watts of power to Powered Devices (PDs) such as wireless access points, Voice over IP phones and IP cameras. Learn more about PoE.
The IDS-105GPP is a 5 to 7 port Industrial Gigabit Ethernet switch providing advanced performance enabling real-time deterministic network operation. It requires no configuration and will operate instantly as soon as you power it up.
IDS-105G are rugged fan-less switches that are hardened to provide superior reliability in 0 to 60°C, or harsh extended operating temperatures from -40 to 75°C. They come in a variety of models with 5 copper ports, 5 copper ports plus 1 fiber port or 5 copper ports plus 2 fiber ports.
Perle has been designing industrial hardware for serial ModBus and Profinet to Ethernet conversion environments for over 35 years and have used this expertise to design the toughest Ethernet switches on the market. Don't trust your critical communications to commercial switch products. Perle Industrial Ethernet switches give you proven assurance that your system will keep running for years to come.
- Gigabit Ethernet port for ultra-fast network speeds
- Up to 10x faster than standard Ethernet server connectivity while providing high-performance uplinks
- The switch is rail mountable, you can easily install it in racks with concrete stability
- Layer 2 switch provides a complete lineup of features including IGMP snooping, port mirroring, and spanning tree
- The unmanaged switch provides a quick, easy and cost-saving way to add wired networking to your home, office or small business; no intervention needed
- Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
- Electrical power is transmitted along with data in a single cable to devices such as Access Points, IP cameras or IP phones
- Built-in power supply to ensure all components are being supplied with accurate voltage
- Quickly and easily set up a wired network with 6 networking ports
- Create your own LAN and connect your PC, laptop, printer and other peripherals with the help of 6 ports
Spécifications techniques
| Management & Protocols | |
| Manageable | No |
| Network & Communication | |
| Layer Supported | 2 |
| Power Description | |
| Power Source | Power Supply |
| PoE (RJ-45) Port | Yes |
| Redundant Power Supply Supported | Yes |
| Miscellaneous | |
| Package Contents |
|
| Certifications & Standards | IEEE Standards:
Safety:
|
| Country of Origin | Taiwan |
| Environmentally Friendly | Yes |
| Media & Performance | |
| Network Technology | 1000Base-SX |
| 10/100/1000Base-T | |
| Ethernet Technology | Gigabit Ethernet |
| Media Type Supported | Twisted Pair |
| Optical Fiber | |
| Fiber Mode Supported | Multi-mode |
| General Information | |
| Product Type | Ethernet Switch |
| Manufacturer Part Number | 07011700 |
| Manufacturer Website Address | http://www.perle.com |
| Manufacturer | Perle Systems, Inc |
| Product Model | IDS-105GPP-M2SC05 |
| Product Name | IDS-105GPP-M2SC05 - Industrial Ethernet Switch with Power Over Ethernet |
| Brand Name | Perle |
| Physical Characteristics | |
| Weight (Approximate) | 13.05 oz (370 g) |
| Form Factor | Wall Mountable |
| Panel-mountable | |
| Rail-mountable | |
| Height | 1.40" (35.50 mm) |
| Width | 4.37" (111 mm) |
| Depth | 5.43" (138 mm) |
| Interfaces/Ports | |
| Token Ring Port | No |
| LRE Port | No |
| USB | No |
| Number of Network (RJ-45) Ports | 1 |
| Modular | No |
| Management Port | No |
| Uplink Port | No |
| Number of PoE (RJ-45) Ports | 4 |
| Stack Port | No |
| Number of SC Ports | 1 |
| Bypass | No |
| Total Number of Network Ports | 6 |
| SC Port Type | Duplex |
| Port/Expansion Slot Details | 6 x Gigabit Ethernet Network |
