À propos du produit
APC Metered by Outlet with Switching Rack Power Distribution Units (PDUs) enable advanced, user-customizable power control and individual outlet power metering. Remote outlet level controls allow power on/off functionality for power recycling to reboot locked-up equipment and to avoid unauthorized use of individual outlets. Power sequencing delays allow users to define the order in which to power up or down attached equipment. Avoid circuit overload during power recovery and extend uptime of critical equipment by prioritizing the load shedding. Current metering provides real-time remote monitoring of connected loads. Switched Rack PDUs include real power monitoring, a temperature/humidity sensor port, and locking IEC receptacles. User-defined alarms warn of potential circuit overloads before critical IT failures occur. Users can access, configure, and control Switched rack PDUs through secure Web, SNMP, or Telnet Interfaces and is complimented by APC Centralized Management platforms using InfraStruxure Central, Capacity Manager and Change Manager.
- Network management
- Remote individual outlet control
- Power delays
- Load indicator LED
- Integrates with InfraStruXure Central
- Single input power source
- PDU is reliable for power protection and management solutions
- With switched PDU, remotely monitor, connect or disconnect data center loads
Spécifications techniques
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Management | |
| Management |
|
| Remote Outlet Switching | Yes |
| Environmental Conditions | |
| Minimum Operating Temperature | 23°F (-5°C) |
| Maximum Operating Temperature | 113°F (45°C) |
| Minimum Operating Humidity | 5% |
| Maximum Operating Humidity | 95% |
| Miscellaneous | |
| Package Contents |
|
| Compatibility | Schneider APC Products:
https://www.dell.com/en-ca/shop/rack-pdu-2g-switched-plus-200-208v-30a-l6-30p-0u-21xc13-3xc19/apd/a7438542/power-cooling-data-center-infrastructure |
| Certifications & Standards |
|
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) | |
| Power Description | |
| Input Voltage | 230 V AC |
| Output Voltage | 208 V AC |
| 200 V AC | |
| Input Current | 24 A |
| Input Voltage Range | 200 V AC - 240 V AC |
| Input Frequency | 60 Hz |
| General Information | |
| Product Type | PDU |
| Manufacturer Part Number | A7438542 |
| Manufacturer Website Address | http://www1.ca.dell.com |
| Manufacturer | Dell Technologies |
| Product Model | AP8641 |
| Product Name | AP8641 24-Outlets PDU |
| Brand Name | Dell |
| Physical Characteristics | |
| Weight (Approximate) | 8.20 kg |
| Mount Type | Rack-mountable |
| Rack Height | 0U |
| Cord Length | 9.8 ft |
| Height | 72.05" (1830 mm) |
| Width | 2.20" (56 mm) |
| Depth | 2.01" (51 mm) |
| Product Color | Black |
| Color Family | Black |
| Technical Information | |
| Features | LCD Display |
| Protection Type | Overload Protection |
| Plug/Connector Type | NEMA L6-30P |
| Receptacle Type | IEC 60320 C13 |
| IEC 60320 C19 | |
| PDU Type | Metered-by-Outlet |
| Switched | |
| Receptacle Detail | 3 x IEC 60320 C19 |
| 21 x IEC 60320 C13 | |
| Plug/Connector Detail | 1 x NEMA L6-30P |
