Power Distribution
The growing complexity of IT environments, from wiring closets and server rooms to data centers of all sizes, has increased the need for reliable power distribution to the rack level. Eliminating power management issues is essential for IT and Facilities managers to maintain system availability of increasing higher density equipment. Power Distribution Units are an essential element in managing power capacity and functionality for critical network, server and data center equipment.
APC provides a wide array of power distribution solutions for your IT environment. APCs standardized PDUs are designed to increase the manageability and efficiency of your data center. Power Distribution solutions provide real-time remote load monitoring of connected equipment and individual outlet power control for remote power recycling, manage power-up or power-down sequencing of equipment. IT and Data Center Managers rely on APC PDU alarms to warn of potential power overloads before critical IT failures occur.
AP9567 Features
- Toolless Rack Mounting Capabilities - Server cases do not require additional tools to mount into NetShelter Enclosures, which allows the users to quickly and easily mount units in the rear of the enclosure.
- Vertical Mounting Capabilities - Easily mounts vertically in racks or enclosures and occupies zero U of valuable rack space, which allows more equipment in the rack. Units that mount vertically are optimized to fit in a NetShelter enclosures.
Agility
- Rack-Mountable - Includes horizontal, vertical, and toolless-mount varieties. Puts power where it is needed most - in the racks near the equipment.
- Single input power source - Supply power from one branch whip to multiple pieces of equipment, conveniently powering rack-mount equipment. Saves time and money during installation by using one branch whip and standard connections.
- Wide range of input and output connections - Product family includes a variety of input and output connections to distribute 120V, 208V, or 230V power to multiple outlets. Having a variety of inputs and outputs allow users to adapt to varying power requirements. APC offers units that bring up to 14.4kW using a single branch whip.
- With PDUs decisions for load balancing and minimizing extra cost can be managed
- Basic PDU deliver power to wiring closets, server rooms & equipment racks in a cost-effective way
Spécifications techniques
| Warranty | |
| Additional Warranty Information |
|
| Environmental Conditions | |
| Minimum Operating Temperature | 32°F (0°C) |
| Maximum Operating Temperature | 113°F (45°C) |
| Minimum Storage Temperature | -13°F (-25°C) |
| Maximum Storage Temperature | 149°F (65°C) |
| Minimum Operating Humidity | 0% |
| Maximum Operating Humidity | 95% |
| General Information | |
| Product Type | PDU |
| Manufacturer Part Number | A7541364 |
| Manufacturer Website Address | http://www1.ca.dell.com |
| Manufacturer | Dell Technologies |
| Product Model | AP9567 |
| Product Name | AP9567 14-Outlets PDU |
| Brand Name | Dell |
| Miscellaneous | |
| Application/Usage | Server |
| Data Center | |
| IT Equipment | |
| Package Contents |
|
| Compatibility | Schneider APC Products:
https://www.dell.com/en-ca/shop/apc-basic-rack-mount-pdu-power-distribution-strip-rack-mountable-ac-120-v-0u-15a-14-5-15/apd/a7541364/power-cooling-data-center-infrastructure#techspecs_section |
| Certifications & Standards |
|
| Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Restriction of Hazardous Substances (RoHS) | |
| Power Description | |
| Circuit Breaker | Yes |
| Input Voltage | 120 V AC |
| Output Voltage | 120 V AC |
| 100 V AC | |
| Input Current | 15 A |
| Input Voltage Range | 100 V AC - 125 V AC |
| Input Frequency | 60 Hz |
| Power Rating (VA) | 1.80 kVA |
| Power Rating (Watt) | 14.40 kW |
| Technical Information | |
| Protection Type | Overload Protection |
| Circuit Protection | |
| Plug/Connector Type | NEMA 5-15P |
| Receptacle Type | NEMA 5-15R |
| Load Capacity (VA) | 1.80 kW |
| Load Capacity (Watt) | 14.40 kW |
| PDU Type | Basic |
| Receptacle Detail | 14 x NEMA 5-15R |
| Plug/Connector Detail | 1 x NEMA 5-15P |
| Physical Characteristics | |
| Weight (Approximate) | 2.20 kg |
| Mount Type | Rack-mountable |
| Rack Height | 0U |
| Cord Length | 12.1 ft |
| Height | 24.02" (610 mm) |
| Width | 1.77" (45 mm) |
| Depth | 1.77" (45 mm) |
| Mounting Orientation | Horizontal/Vertical |
| Product Color | Black |
| Color Family | Black |
