À propos du produit
- DisplayPort transmits both audio and video signals through a common channel to deliver versatile performance
- Micro ATX form factor brings a significant number of PCI slots, expansion slots, and peripheral ports with an enhanced heat dissipation capability
- DDR3 SDRAM compatible slot - Install memory that synchronizes electrical and clock signals for an efficient data throughput
- RAID supported levels provide data reliability and fault tolerance
- Compatible Intel Core i5 processor provides you with the solid performance to watch videos and play games, while its adaptability makes you more productive
Spécifications techniques
| Network & Communication | |
| Gigabit Ethernet | Yes |
| Video | |
| Graphics Controller Model | HD Graphics |
| Onboard Video | CPU Dependent Video |
| Onboard Interfaces | |
| Number of SATA Interfaces | 6 |
| Total Number of Onboard USB Ports | 8 |
| Number of Onboard USB 2.0 Ports | 8 |
| I/O Expansions | |
| Number of PCI Express x4 Slots | 1 |
| Number of PCI Express x16 Slots | 1 |
| Total Number of PCI Express Slots | 2 |
| Total Number of Expansion Slots | 4 |
| Physical Characteristics | |
| Weight (Approximate) | 2.65 lb (1200 g) |
| Form Factor | Micro ATX |
| Width | 9.61" (244 mm) |
| Depth | 9.61" (244 mm) |
| I/O Controller | |
| RAID Levels | 10 |
| 5 | |
| 1 | |
| 0 | |
| Controller Type | Serial ATA/600 |
| RAID Supported | Yes |
| Interfaces/Ports | |
| DVI | Yes |
| VGA | Yes |
| Number of Network (RJ-45) Ports | 2 |
| DisplayPort | Yes |
| Total Number of USB Ports | 4 |
| Number of USB 3.0 Ports | 4 |
| Memory | |
| Maximum Memory Supported | 32 GB |
| Memory Technology | DDR3 SDRAM |
| Number of Memory Slots | 4 |
| Memory Form Factor | DIMM |
| Memory Speed Supported | 1333 MHz |
| 1600 MHz | |
| Miscellaneous | |
| Package Contents |
|
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Energy Star | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Waste Electrical and Electronic Equipment Directive (WEEE) | |
| General Information | |
| Product Type | Desktop Motherboard |
| Manufacturer Part Number | AIMB-582QG2-TPA1E |
| Manufacturer Website Address | http://www.advantech.com |
| Manufacturer | Advantech Co., Ltd |
| Product Model | AIMB-582 |
| Product Name | AIMB-582 Desktop Motherboard |
| Brand Name | Advantech |
| Processor & Chipset | |
| Processor Supported | Core i3 |
| Core i5 | |
| Core i7 | |
| Celeron | |
| Pentium | |
| Total Processor Supported | 1 |
| Chipset Manufacturer | Intel |
| Chipset Model | Q77 Express |
