À propos du produit
It is a basic rack PDU with a 1U horizontal mounting design. It supports a maximum input current of 20A and operates at 100-240V. The PDU features 7 IEC 60320 C13 outlets and 2 IEC 60320 C19 outlets. It includes an IEC 60320 C20 plug. It is compliant with RoHS and REACh regulations, ensuring it meets environmental standards.
- PDU improves efficiency, uptime and growth of data centers
- PDU allows power to be more efficiently distributed and controlled
- Basic PDU is the space-saving and cost-effective way to deliver power
- Basic PDU deliver power to wiring closets, server rooms & equipment racks in a cost-effective way
Spécifications techniques
| Warranty | |
| Additional Warranty Information | 2 years repair or replace |
| Technical Information | |
| Plug/Connector Type | IEC 60320 C20 |
| PDU Type | Basic |
| General Information | |
| Product Type | PDU |
| Manufacturer Part Number | AP6120A |
| Manufacturer Website Address | http://www.schneider-electric.com |
| Manufacturer | Schneider Electric SA |
| Product Model | AP6120A |
| Product Name | Basic Rack PDU AP6120A |
| Product Line | NetShelter |
| Product Series | Basic |
| Brand Name | APC by Schneider Electric |
| Physical Characteristics | |
| Weight (Approximate) | 3.44 lb (1560.36 g) |
| Form Factor | Tower |
| Mount Type | Rack-mountable |
| Rack Height | 1U |
| Placement | Front |
| Rear | |
| Height | 1.73" (44 mm) |
| Width | 15.28" (388 mm) |
| Depth | 3.66" (93 mm) |
| Mounting Orientation | Horizontal |
| Mounting Preference | No Preference |
| Power Description | |
| Input Voltage | 240 V |
| 208 V | |
| 200 V | |
| 120 V | |
| 100 V | |
| 230 V | |
| Output Voltage | 208 V AC |
| 230 V AC | |
| 240 V AC | |
| 120 V AC | |
| 100 V AC | |
| 200 V AC | |
| Input Current | 20 A |
| Miscellaneous | |
| Package Contents | |
| Certifications & Standards | cUL Listed|CE|EAC|IRAM|PSE|UL Listed|VDE |
| Country of Origin | India |
| Environmentally Friendly | Yes |
| Mercury Free | Yes |
| For Country/Region | United States |
| Optimized Energy Efficiency | Yes |
| Product Take Back Program | Yes |
| RoHS Exemption Information | https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=AP6120A_ROHS_DECLARATION&p_FileName=AP6120AKIT_ROHS_DECLARATION_US.pdf |
| REACH Declaration URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=458562842&lang=en-us |
| EU RoHS Declaration URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=458562842&lang=en-us |
| Environmental Profile Availability | https://download.schneider-electric.com/files?p_enDocType=Environmental+Disclosure&p_Doc_Ref=ENVPEP1512009_EN |
| End of Life Manual Availability | https://download.schneider-electric.com/files?p_enDocType=Circularity+Profile&p_Doc_Ref=ENVEOLI1512009_EN |
| REACH free of SVHC | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
