À propos du produit
APC Switched Rack Power Distribution Units (PDUs) enable advanced, user-customizable power control and active monitoring. Remote outlet level controls allow power on/off functionality for power recycling to remotely reboot equipment and restrict unauthorized use of individual outlets. Power sequencing delays allow users to define the order in which to power up or down attached equipment. Avoid circuit overload during power recovery and extend uptime of critical equipment by prioritizing the load shedding. Current metering provides real-time remote monitoring of connected loads. Switched Rack PDUs include real power monitoring, a temperature/humidity sensor port, locking IEC receptacles, and low profile circuit breakers. User-defined alarms warn of potential circuit overloads before critical IT failures occur. Users can access, configure, and control Switched Rack PDUs through secure Web, SNMP, or Telnet Interfaces and is complimented by APC Centralized Management platforms using InfraStruxure Central, Capacity Manager and Change Manager.
Spécifications techniques
| Management | |
| Management |
|
| Miscellaneous | |
| Package Contents | |
| Certifications & Standards |
|
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) | |
| General Information | |
| Product Type | PDU |
| Manufacturer Part Number | AP8970 |
| Manufacturer Website Address | http://www.schneider-electric.com |
| Manufacturer | Schneider Electric SA |
| Product Name | Switched Rack PDU |
| Brand Name | APC by Schneider Electric |
| Power Description | |
| Circuit Breaker | Yes |
| Input Voltage | 120 V AC |
| 230 V AC | |
| Output Voltage | 208 V AC |
| 120 V AC | |
| Input Current | 30 A |
| Input Voltage Range | 120 V AC - 230 V AC |
| Power Rating (VA) | 5.76 kVA |
| Technical Information | |
| Protection Type | Overload Protection |
| Plug/Connector Type | NEMA L14-30P |
| Receptacle Type | IEC 60320 C19 |
| NEMA 5-20R | |
| IEC 60320 C13 | |
| PDU Type | Switched |
| Receptacle Detail | 16 x NEMA 5-20R |
| 7 x IEC 60320 C13 | |
| 1 x IEC 60320 C19 | |
| Physical Characteristics | |
| Weight (Approximate) | 17.91 lb (8123.84 g) |
| Form Factor | Tower |
| Mount Type | Rack-mountable |
| Rack Height | 0U |
| Cord Length | 10 ft (3.05 m) |
| Height | 72" (1828.80 mm) |
| Width | 2.18" (55.37 mm) |
| Depth | 1.82" (46.23 mm) |
| Number of Cord/Cable | 1 |
| Mounting Orientation | Horizontal/Vertical |
| Product Color | Black |
| Color Family | Black |
