À propos du produit
- Fast Ethernet technology gives ideal solution for extending network connections to conference rooms, labs, lobbies and department workgroups
- Layer 2 switch provides a complete lineup of features including IGMP snooping, port mirroring, and spanning tree
- Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
- Quickly and easily set up a wired network with 24 networking ports
- Create your own LAN and connect your PC, laptop, printer and other peripherals with the help of 24 ports
Spécifications techniques
| Network & Communication | |
| Layer Supported | 2 |
| Warranty | |
| Additional Warranty Information | 2 years repair or replace |
| Interfaces/Ports | |
| Number of Network (RJ-45) Ports | 24 |
| Network (RJ-45) | Yes |
| Total Number of Network Ports | 24 |
| Port/Expansion Slot Details | IEC 60320 C14 |
| Media & Performance | |
| Network Technology | 10Base-T |
| 10/100Base-TX | |
| Twisted Pair Cable Standard | Category 5 |
| Ethernet Technology | Fast Ethernet |
| Media Type Supported | Twisted Pair |
| General Information | |
| Product Type | Ethernet Switch |
| Manufacturer Part Number | AP9224110 |
| Manufacturer Website Address | http://www.schneider-electric.com |
| Packaged Quantity | 1 Each |
| Manufacturer | Schneider Electric SA |
| Product Model | AP9224110 |
| Product Name | 24-Port 10/100 Ethernet Switch |
| Brand Name | APC by Schneider Electric |
| Power Description | |
| Input Voltage | 208 V |
| 100 V | |
| 120 V | |
| 200 V | |
| 230 V | |
| Power Source | Power Supply |
| Input Receptacles | IEC 60320 C14 |
| Plug/Connector Type | IEC 60320 C14 |
| Physical Characteristics | |
| Weight (Approximate) | 2.60 lb (1179.34 g) |
| Form Factor | Rack-mountable |
| Desktop | |
| Height | 1.46" (37 mm) |
| Width | 9.84" (250 mm) |
| Depth | 5.20" (132 mm) |
| Compatible Rack Unit | 1U |
| Product Color | Black |
| Color Family | Black |
| Miscellaneous | |
| Additional Information |
|
| Package Contents |
|
| Certifications & Standards | cUL Listed|CE|TÜV|UL Listed |
| Country of Origin | Philippines |
| Environmentally Friendly | Yes |
| Mercury Free | Yes |
| Green Premium | Yes |
| Product Take Back Program | Yes |
| RoHS Exemption Information | https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=AP9224110_ROHS_DECLARATION&p_FileName=AP9224110KIT_ROHS_DECLARATION_US.pdf |
| REACH Declaration URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=759378&lang=en-us |
| EU RoHS Declaration URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=759378&lang=en-us |
| Environmental Profile Availability | https://download.schneider-electric.com/files?p_enDocType=Environmental+Disclosure&p_Doc_Ref=ENVPEP1512008 |
| End of Life Manual Availability | https://download.schneider-electric.com/files?p_enDocType=Circularity+Profile&p_Doc_Ref=ENVEOLI1512008_EN |
| REACH free of SVHC | No |
| WEEE Statement | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
