À propos du produit
Les transformateurs abaisseurs APC sont utilisés pour convertir une tension d'entrée plus élevée (208 V-200 V) en une tension de sortie plus faible (120 V-100 V) qui peut être plus adaptée à certains environnements ou configurations système.
Spécifications techniques
| Warranty | |
| Additional Warranty Information | 2 years repair or replace |
| Power Description | |
| Input Voltage | 208 V |
| Output Voltage | 120 V AC |
| Maximum Line Current | 26 A |
| Technical Information | |
| Power Rating | 5 kVA |
| Input Receptacle Type | Hard Wire 3-wire (2PH + G) |
| Output Receptacle Detail | 1 x Hard Wire 3-wire (H+N+E) |
| Output Receptacle Type | Hard Wire 3-wire (H+N+E) |
| General Information | |
| Product Type | Step Down Transformer |
| Manufacturer Part Number | AP9628 |
| Manufacturer Website Address | http://www.schneider-electric.com |
| Packaged Quantity | 1 Each |
| Manufacturer | Schneider Electric SA |
| Product Name | 5000VA Step-Down Rack-mountable Transformer |
| Brand Name | APC by Schneider Electric |
| Physical Characteristics | |
| Weight (Approximate) | 95.20 lb (43181.99 g) |
| Form Factor | Rack-mountable |
| Rack Height | 2U |
| Height | 3.50" (89 mm) |
| Width | 17.52" (445 mm) |
| Depth | 24.02" (610 mm) |
| Product Color | Black |
| Color Family | Black |
| Mounting Location | Front |
| Mounting Preference | No Preference |
| Miscellaneous | |
| Package Contents | |
| Certifications & Standards | CSA|UL Listed |
| Environmentally Friendly | Yes |
| Mercury Free | Yes |
| For Country/Region | United States |
| Optimized Energy Efficiency | Yes |
| Product Take Back Program | Yes |
| RoHS Exemption Information | https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=AP9635_ROHS_DECLARATION&p_FileName=AP9635KIT_ROHS_DECLARATION_US.pdf |
| REACH Declaration URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=759642&lang=en-us |
| EU RoHS Declaration URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=759642&lang=en-us |
| Environmental Profile Availability | https://download.schneider-electric.com/files?p_enDocType=Environmental+Disclosure&p_Doc_Ref=ENVPEP1511005_EN |
| End of Life Manual Availability | https://download.schneider-electric.com/files?p_enDocType=Circularity+Profile&p_Doc_Ref=ENVEOLI1511005_EN |
| Lead Free | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
