À propos du produit
Ce transformateur d'isolement supporte une capacité de charge de 20 kVA. Il est conçu pour un montage en rack 4U. L'unité comprend des supports de montage, un manuel d'utilisation, un guide d'installation, un panneau de câblage et un CD de documentation.
Spécifications techniques
| Warranty | |
| Additional Warranty Information | 2 years repair or replace |
| General Information | |
| Product Type | Isolation Transformer |
| Manufacturer Part Number | APTF20KW01 |
| Manufacturer Website Address | http://www.schneider-electric.com |
| Manufacturer | Schneider Electric SA |
| Product Name | 20kVA Isolation Rack-mountable Transformer |
| Brand Name | APC by Schneider Electric |
| Technical Information | |
| Power Rating | 20 kVA |
| Input Receptacle Type | Hard Wire 3 wire (1PH+N+G) |
| Hard Wire 3-wire (2PH + G) | |
| Hard Wire 4-wire (2PH+N+G) | |
| Output Receptacle Detail | 1 x Hard Wire 4-wire (2PH+N+G) |
| 1 x Hard Wire 3-wire (2PH + G) | |
| 1 x Hard Wire 3-wire (H+N+E) | |
| Output Receptacle Type | Hard Wire 4-wire (2PH+N+G) |
| Hard Wire 3-wire (2PH + G) | |
| Hard Wire 3-wire (H+N+E) | |
| Physical Characteristics | |
| Weight (Approximate) | 260.54 lb (118178.96 g) |
| Form Factor | Rack-mountable |
| Rack Height | 4U |
| Height | 6.89" (175 mm) |
| Width | 17.01" (432 mm) |
| Depth | 29.80" (757 mm) |
| Product Color | Black |
| Color Family | Black |
| Mounting Location | Side |
| Front | |
| Mounting Preference | Lower |
| Power Description | |
| Input Voltage | 230 V |
| 208 V | |
| 200 V | |
| 120 V | |
| 100 V | |
| 400 V | |
| Output Voltage | 100 V |
| 120 V | |
| 200 V AC | |
| 208 V AC | |
| 230 V AC | |
| Maximum Line Current | 100 A |
| Miscellaneous | |
| Package Contents | |
| Certifications & Standards | CSA|UL Listed |
| Environmentally Friendly | Yes |
| Mercury Free | Yes |
| For Country/Region | United States |
| Optimized Energy Efficiency | Yes |
| Product Take Back Program | Yes |
| RoHS Exemption Information | https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=APTF20KW01_ROHS_DECLARATION&p_FileName=APTF20KW01KIT_ROHS_DECLARATION_US.pdf |
| REACH Declaration URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=759850&lang=en-us |
| EU RoHS Declaration URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=759850&lang=en-us |
| Environmental Profile Availability | https://download.schneider-electric.com/files?p_enDocType=Environmental+Disclosure&p_Doc_Ref=ENVPEP1511005_EN |
| End of Life Manual Availability | https://download.schneider-electric.com/files?p_enDocType=Circularity+Profile&p_Doc_Ref=ENVEOLI1511005_EN |
| REACH free of SVHC | No |
| Toxic Heavy Metal Free | Yes |
| WEEE Statement | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
