À propos du produit
- Intel® Celeron J1900 Quad Core 2.0 GHz SoC
- 1 x 2.5" SATA HDD/SSD Bay
- 2 x GbE for Multiple Internet Transmission
- 2 x Independent HDMI
- 1 x RS-232/422/485 (BIOS selection)
- 1 x Full-Size MiniPCIe (ex. WLAN or WWAN module)
- 1 x Half Size mSATA
- Threaded DC jack design with optional VESA / DIN Rail / Wall Mounting kits
- Supports SUSIAccess, Embedded Software APIs and WIFI 802.11 a/b/g/n bundled for IoT Gateway
Spécifications techniques
| Chipset | |
| Chipset Manufacturer | Intel |
| Controllers | |
| Controller Type | Serial ATA |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Display & Graphics | |
| Graphics Memory Technology | DDR3L SDRAM |
| Graphics Memory Accessibility | Shared |
| I/O Expansions | |
| Number of Total Expansion Bays | 1 |
| Total Number of Expansion Slots | 1 |
| Power Description | |
| Number of Power Supplies Installed | 1 |
| Maximum Power Supply Wattage | 36 W |
| Storage | |
| Supported Storage Drive Interfaces | mSATA |
| Serial ATA | |
| Interfaces/Ports | |
| HDMI | Yes |
| Total Number of USB Ports | 3 |
| Number of USB 3.0 Ports | 1 |
| Memory | |
| Maximum Memory Supported | 8 GB |
| Memory Technology | DDR3L SDRAM |
| Memory Standard | DDR3L-1333/PC3-10600 |
| Total Number of Memory Slots | 1 |
| Miscellaneous | |
| Package Contents |
|
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Taiwan Restriction of Hazardous Substances (Taiwan RoHS) | |
| Physical Characteristics | |
| Weight (Approximate) | 1.76 lb (800 g) |
| Form Factor | Box PC |
| Height | 1.70" (43.18 mm) |
| Width | 5.27" (133.86 mm) |
| Depth | 3.71" (94.23 mm) |
| Processor | |
| Processor Speed | 2 GHz |
| Processor Type | Celeron |
| Processor Model | J1900 |
| Processor Core | Quad-core (4 Core) |
| Maximum Turbo Speed | 2.41 GHz |
| Operating System | |
| Operating System Supported | Linux |
| Windows 10 | |
| Windows 8 | |
| Windows Embedded 8 Standard | |
| Windows Embedded Standard 7 | |
| Windows 7 | |
| General Information | |
| Product Type | Barebone System |
| Manufacturer Part Number | ARK-1123H-U0A2E |
| Manufacturer Website Address | http://www.advantech.com |
| Packaged Quantity | 1 |
| Manufacturer | Advantech Co., Ltd |
| Product Model | ARK-1123H |
| Product Name | Intel Celeron Quad Core J1900 SoC with Dual HDMI/GbE IoT Fanless Box PC |
| Brand Name | Advantech |
