À propos du produit
The Allied Telesis GS920 Series offers DIP Smart Gigabit switching solutions for the desktop and small networks. Front-panel DIP switches provide easy configuration of commonly-used features, without the need for a PC.
DIP switches
GS920 series switches provide port configuration for Speed/Duplex, Loop Detection and Flooding mode. The ability to set up the DIP switch without a PC saves money and time.
High performance
The GS920 Series delivers ultra-fast speed and high performance for today's high-bandwidth applications, such as video, graphics and industrial design, using Gigabit Ethernet.
Quality and reliability
Allied Telesis is a world leader in unmanaged Ethernet switches, and ships more than 250,000 unmanaged switches every year. Allied Telesis offers both proven reliability and industry-leading quality.
Speed/duplex configuration
The GS920 Series allows speed and duplex to be set on a per-port basis. This supports older devices where auto-negotiation is not supported, as well as embedded devices which may support a fixed speed/duplex only.
Loop detection
The Loop Detection feature discovers network loops, and shuts down affected ports. After the loop is resolved, affected ports are automatically returned to active use.
Flooding mode
Flooding mode allows the easy capture of data streams for troubleshooting and analysis, as they are sent to all ports.
- Gigabit Ethernet port for ultra-fast network speeds
- With leading Layer 2 support, experience enhanced convenience, secure business operations, and a borderless network experience
- Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
- Built-in power supply to ensure all components are being supplied with accurate voltage
- Quickly and easily set up a wired network with 8 networking ports
Spécifications techniques
| Management & Protocols | |
| Manageable | No |
| Network & Communication | |
| Layer Supported | 2 |
| Power Description | |
| Power Source | Power Supply |
| Interfaces/Ports | |
| Total Number of Network Ports | 8 |
| Port/Expansion Slot Details | 8 x Gigabit Ethernet Network |
| Media & Performance | |
| Network Technology | 10/100/1000Base-T |
| Ethernet Technology | Gigabit Ethernet |
| Media Type Supported | Twisted Pair |
| Miscellaneous | |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Waste Electrical and Electronic Equipment Directive (WEEE) | |
| Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) | |
| Physical Characteristics | |
| Weight (Approximate) | 1.76 lb (800 g) |
| Form Factor | Desktop |
| Rack-mountable | |
| Wall Mountable | |
| Height | 1.50" (38 mm) |
| Width | 8.27" (210 mm) |
| Depth | 4.76" (121 mm) |
| General Information | |
| Product Type | Ethernet Switch |
| Manufacturer Part Number | AT-GS920/8-10 |
| Manufacturer Website Address | http://www.alliedtelesis.com |
| Manufacturer | Allied Telesis, Inc |
| Product Model | GS920/8 |
| Product Name | 8-Port 10/100/1000T UnManaged Switch With Internal PSU |
| Product Series | GS920 |
| Brand Name | Allied Telesis |
