À propos du produit
Two-Port HDMI splitter transmits Ultra High Definition (UHD) 4K x 2K audio/video (A/V) from an HDMI source to two HDMI displays at the same time. Plug-and-play technology makes installation quick and simple - with no software or drivers to install. Using standard 28 AWG HDMI cabling, this splitter can transmit full 3D and a 4K x 2K (3840 x 2160) signal up to 15'. It supports a wide range of audio formats, including DTS-HD, Dolby TrueHD, Dolby Digital Plus, and LPCM 7.1-channel surround sound as well as 36-bit Deep Color (12 bits per channel). Splitter also supports HDMI 2.0 and HDCP 2.2 to ensure its compatibility with the latest audio/video hardware.
- Transmits UHD video resolutions up to 4K x 2K @ 60 Hz
- Distributes A/V up to 15 ft. when used with 28 AWG HDMI cable
- Supports DTS-HD, Dolby® TrueHD and Dolby Digital Plus™
- Compatible with HDCP 2.2, 3D, EDID and HDMI 2.0
- Supports High Dynamic Range (HDR) for richer contrast and expanded color accuracy
- Expand the number of connected displays, up to 32, by cascading up to 3 levels of splitters together
- Plug and play-no software or drivers required
- 3-year limited warranty
Spécifications techniques
| Media & Performance | |
| Maximum Operating Distance | 22.97 ft (7000 mm) |
| Physical Characteristics | |
| Product Material | Metal |
| Video | |
| Maximum Video Resolution | 3840 × 2160 |
| Warranty | |
| Additional Warranty Information | 3 year limited warranty |
| Power Description | |
| Input Voltage | 5 V DC |
| 230 V AC | |
| 120 V AC | |
| Interfaces/Ports | |
| Number of HDMI Inputs | 1 |
| Number of HDMI Outputs | 2 |
| HDMI In | Yes |
| HDMI Out | Yes |
| Miscellaneous | |
| Package Contents |
|
| Country of Origin | Taiwan |
| TAA Compliant | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| General Information | |
| Product Type | Signal Splitter |
| Manufacturer Part Number | B118-002-UHD-2 |
| Manufacturer Website Address | http://www.eaton.com/EatonCom/Markets/NorthAmerica |
| Packaged Quantity | 1 Each |
| Manufacturer | Eaton Corporation |
| Product Model | B118-002-UHD-2 |
| Product Name | B118-002-UHD-2 2-Port 4K 3D HDMI Splitter |
| Brand Name | Tripp Lite series |
