À propos du produit
Honeywell's Orbit series of scanners provide aggressive omnidirectional scanning in an award-winning design for retailers seeking an affordable, aesthetically-pleasing scanning solution.
Orbit, the all-time, best-selling hands-free omnidirectional scanner, presents an innovative, elegant and affordable solution for convenience retail applications where counter space is at a premium.
Compact, lightweight and rugged, Orbit maximizes customer satisfaction and employee efficiency with a patented 20-line scan pattern, an easy-to-find sweet spot and a scan speed of 1,120 scans per second.
Recipient of multiple design honors, Orbit's award-winning shape enables hand-held scanning of large, bulky items. For added flexibility, the scanning head can be tilted within a 30° range to accommodate objects of various sizes and shapes.
For applications that require menu scanning, OrbitCG 7180 combines the power of patented CodeGate technology with many of the outstanding features already found in the Orbit 7120. CodeGate technology allows the user to easily target the desired bar code and complete data transmission with the push of a single button.
The scanner's expanded ability to update its firmware via Honeywell's free patented MetroSet®2 configuration software safeguards longterm infrastructure commitments in the event of a change in the POS system or software.
Standard features include an integrated EAS antenna for tag deactivation (OrbitCG 7180 only), power save mode, user-replaceable cables, Honeywell's patented MetroSelect and MetroSet 2 for easy configuration, data editing and OPOS/JPOS compatibility for easy installation.
Features:
- 20 Scan Line Omnidirectional Pattern: Provides aggressive scanning as an additional benefit to hand presentation applications
- Sweet Spot Scanning: Engineered "sweet spot" to optimize scan performance and first pass read rate
- Adjustable Scan Head: Ability to tilt scanner 30° for targeted scanning or larger products
- Flash ROM: Protects POS investment with free firmware updates via MetroSet 2 software and standard PC
- Automatic Scanning Operation: Simply present a bar code and the unit scans in a single pass
- Built-in RF EAS Antenna (Orbit 7180 only): Increases efficiency by simultaneously deactivating RF EAS tags and decoding bar codes
- Wired connectivity makes this scanner ideal for retail and desktop applications
- Laser scan engine guarantees rapid error free data entry
Spécifications techniques
| Interfaces/Ports | |
| Host Interface | Serial |
| Power Description | |
| Input Current | 180 mA |
| Standby Current | 170 mA |
| Power Supply Included | Yes |
| Maximum Operating Power Consumption | 900 mW |
| Miscellaneous | |
| Application/Usage | Retail |
| Convenience Store | |
| Package Contents |
|
| Platform Supported | PC |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Physical Characteristics | |
| Weight (Approximate) | 14.11 oz (400 g) |
| Form Factor | Handheld |
| Length | 4.13" (105 mm) |
| Height | 5.91" (150 mm) |
| Width | 4.02" (102 mm) |
| Rugged | Yes |
| General Information | |
| Product Type | Barcode Scanner Kit |
| Manufacturer Part Number | MK712031B416N |
| Manufacturer Website Address | http://www.honeywell.com |
| Manufacturer | Honeywell International, Inc |
| Product Model | MK7120 |
| Product Name | Orbit MK7120 Barcode Scanner Kit |
| Product Line | Orbit |
| Brand Name | Honeywell |
| Technical Information | |
| Barcode Symbology Supported | Reads standard 1D and GS1 DataBar symbologies |
| Connectivity Technology | Cable |
| Features | Notification LED |
| Scanning Distance | 9.80" (248.92 mm) |
| Light Source | Laser |
| Drop Specification | Designed to withstand 1.2 m (4´) drops |
| Scan Pattern | Single Line |
| Omni-directional | |
| Stand Included | Yes |
| Cable Type Included | USB |
| Scanning Capability | 1D |
| Reading Angle (Skew) | 60° |
| Reading Angle (Pitch) | 60° |
| Maximum Ambient Light | 4842 lux |
| Minimum Print Contrast | 35% |
