À propos du produit
Premium features, maximum performance, RFID capabilities and unmatched security for years of use
You need a premium, quality RFID printer that's built to perform flawlessly-day in and day out. Rely on Zebra's ZD621R desktop printer, including RFID printing/encoding, advancing the proven and popular ZD500R. Get it all: an innovative new architecture to power our ever-expanding printer capabilities and software. RFID printing and encoding capabilities in a compact desktop printer. Unmatched security that's constantly evolving to safeguard your sensitive data and shield you from cyberattacks. A new standard 4.3-inch, full-color LCD touch display with intuitive menu. Enhanced features, communication and field-installable media-handling options. And, increased remote-management capabilities. Together, these give you outstanding print performance and industryleading reliability for years of optimal use, and unparalleled intelligence and security to keep you moving forward.
Elevating a Proven Winner
Extending the ZD500R Legacy
Zebra's ZD500R printer/encoder is known for quality, premium performance. You can be confident the next-generation ZD621R includes everything you loved in the legacy printer, and builds on this heritage to deliver best-in-class features and RFID technology for this new era of intelligence
Zebra RFID: More Transformation, No Complication
Print and Encode with Ease
The ZD621R utilizes Zebra's own RE40 RFID module to support a broad range of applications across several industries. Adaptive encoding technology allows for excellent media flexibility and simple RFID calibration, eliminating complex placement guidelines. Optimized to efficiently print and encode labels, the ZD621R gives you greater tracking abilities, deeper visibility and enterprise insights in an ever-competitive business environment.
RFID Backed by the Broadest, Field-Proven Portfolio
Zebra leverages decades of expertise, design thinking and software development to help you deliver maximum RFID gains, while minimizing the pains that can come with multi-vendor solutions. Zebra gives you the industry's broadest, field-proven RFID portfolio for unmatched accuracy and interoperability. Look to Zebra's consistent, fully scaled platform that anticipates real-world challenges and elevates the performance of every system, device, tag and worker.
Expect the Best
Premier Printing Performance
From outstanding print quality to RFID printing/encoding, portability for application flexibility to emerging technology, and fieldinstallable options, the ZD621R is a thermal transfer RFID printer that supports a wide variety of use cases and requirements.
- Capable of printing labels and receipts virtually from anywhere and everywhere
- The printer is capable of printing sharp and detailed monochrome documents quickly
- A better-quality solution to print permanent-use documents
Spécifications techniques
| Memory | |
| Standard Memory | 256 MB |
| Network & Communication | |
| Ethernet | Yes |
| Power Description | |
| Power Source | AC Supply |
| Software | |
| Operating System Supported | Link-OS |
| Interfaces/Ports | |
| USB | Yes |
| Serial Port | Yes |
| USB Host | Yes |
| Display & Graphics | |
| Display Screen | Yes |
| Screen Size | 4.3" (109.22 mm) |
| Touchscreen | Yes |
| Display Screen Type | LCD |
| Physical Characteristics | |
| Weight (Approximate) | 5.50 lb (2494.76 g) |
| Height | 7.50" (190.50 mm) |
| Width | 8" (203.20 mm) |
| Depth | 10.50" (266.70 mm) |
| Fonts & Emulation | |
| Language Emulation | EPL2 |
| XML | |
| ZBI | |
| ZPL | |
| ZPL II | |
| General Information | |
| Product Type | Thermal Transfer Printer |
| Manufacturer Part Number | ZD6A142-301FR1GA |
| Manufacturer Website Address | http://www.zebra.com |
| Manufacturer | Zebra Technologies Corporation |
| Product Model | ZD621R |
| Product Name | ZD621R Thermal Transfer Printer |
| Product Series | ZD621 |
| Brand Name | Zebra |
| Miscellaneous | |
| Package Contents |
|
| Platform Supported | Android |
| iOS | |
| PC | |
| Certifications & Standards | IEC 60950-1, IEC 62368-1, EN55022 Class B, EN55024, EN55035, EN61000- 3-2, EN61000-3-3, FCC Class B, ICES-003, FCC 15.209; 15.247(d), IC RSS 247, EN 300 328, EN 301 893, EN 62311, cTUVus CE Marking, VCCI, C-Tick, S-Mark, CCC, CU, BSMI, KCC, SABS, IN-Metro, BIS, NOM |
| Environmentally Friendly | Yes |
| Cables Included | USB |
| Energy Star | Yes |
| Power Adapter Included | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Media Types & Handling | |
| Media Thickness | 7.5 mil (0.1905 mm) |
| Maximum Roll Diameter | 5" (127 mm) |
| Media Type | Tag Stock |
| Wristband | |
| Tag | |
| Roll Fed | |
| Receipt | |
| Label | |
| Fanfold | |
| Die-cut Label | |
| Continuous Receipt | |
| Continuous Label | |
| Black Mark | |
| Media Sensor | Multi-position Transmissive/Gap Sensor |
| Moveable Reflective/Black Mark Sensor | |
| Full Width Sensor | |
| Maximum Label Width | 4.65" (118 mm) |
| Maximum Label Length | 39.02" (991 mm) |
| Technical Information | |
| Application/Usage | Desktop |
| Barcode Symbology Supported | UPC-A/E |
| Plessey | |
| POSTNET | |
| Codablock | |
| Code 11 | |
| Code 128 | |
| Code 39 | |
| Code 49 | |
| Code 93 | |
| Data Matrix | |
| EAN-13 | |
| EAN-8 | |
| Industrial 2 of 5 | |
| Interleaved 2 of 5 | |
| ISBT-128 | |
| LOGMARS | |
| Maxi Code | |
| Micro PDF | |
| AZTEC | |
| Codabar | |
| MSI | |
| PDF417 | |
| Planet Code | |
| QR Code | |
| Standard 2 of 5 | |
| UPC-A with EAN 2 or 5 Digit Extension | |
| Maximum Print Width | 4.09" (104 mm) |
| Recommended Use | Label/Receipt Print |
| Features | Dual Wall Frame |
| LCD Display | |
| RFID Encoder | |
| RFID Reader | |
| Status Indicator | |
| Print Technology | Thermal Transfer |
| Mobile Device Printing | Yes |
| Print Color Capability | Monochrome |
| Optional Connectivity | Bluetooth |
| Wireless LAN | |
| Real Time Clock | Yes |
| Maximum Print Resolution (dpi) | 203 |
