À propos du produit
The Elo M-Series 1502L widescreen LED touch monitor is a modern and stylish interactive solution for customer engagement and employee effectiveness at the point of sale. The sleek wide aspect ratio touchscreen features full HD edge-to-edge glass with display area real estate to showcase engaging, memorable and rewarding content. An HD display model is available for transactional and other applications not requiring 1920x1080 resolution. For environments where space is scarce, the 1502L is an ideal POS terminal screen or stylish interactive information display. Built to withstand the rigors of continuous public use, the 1502L is well suited for high use retail venues. The sleek, thin look pairs well with any modern store environment.
- The IntelliTouch Pro Projected Capacitive touchscreen technology offers two essential advantages, not only can you touch the panel with your bare finger, but you can also actuate it with surgical gloves or slender cotton gloves on
- LED backlight technology provides for industry-leading low power consumption and less hazardous materials
- The 600:1 contrast ratio produces enhanced sharpness and shading accuracy in each picture
- The 220 cd/m² brightness gives an exceptionally visible display for clear and consistent on-screen pictures
Spécifications techniques
| Miscellaneous | |
| Mean Time Between Failures (MTBF) | 5.7 Year |
| Built-in Devices | |
| Microphone | No |
| Webcam | No |
| Audio | |
| Speakers | Yes |
| Number of Speakers | 2 |
| Speaker Output Power | 4 W |
| Interfaces/Ports | |
| USB | Yes |
| HDMI | Yes |
| VGA | Yes |
| Number of HDMI Inputs | 1 |
| Touchscreen Information | |
| Touchscreen Type | IntelliTouch Pro Projected Capacitive |
| Touchscreen | Yes |
| Multi-touch Screen | Yes |
| Number of Simultaneous Touchpoints | 10 |
| Power Description | |
| Input Voltage Range | 100V to 240V |
| Operating Power Consumption | 10.20 W |
| Standby Power Consumption | 500 mW |
| Off-Mode Power Consumption | 200 mW |
| Energy Consumption per Year | 18 kWh |
| Video | |
| Contrast Ratio | 600:1 |
| Brightness | 220 cd/m² |
| Color Supported | 262,000 Colors |
| Maximum Resolution | 1366 x 768 |
| Native Contrast Ratio | 700:1 |
| General Information | |
| Product Type | LCD Touchscreen Monitor |
| Manufacturer Part Number | E318746 |
| Manufacturer Website Address | http://www.elotouch.com |
| Packaged Quantity | 1 |
| Manufacturer | Elo Touch Solutions, Inc |
| Product Model | 1502L |
| Product Name | M-Series 1502L 15-inch LED Touch Monitor |
| Product Series | M |
| Brand Name | Elo |
| Physical Characteristics | |
| Weight (Approximate) | 6.61 lb (3000 g) |
| Height | 9.62" (244.35 mm) |
| Width | 15.24" (387.10 mm) |
| Depth | 1.29" (32.77 mm) |
| Weight with Stand (Approximate) | 6.72 lb (3050 g) |
| VESA Mount Compatible | Yes |
| VESA Mount Standard | 100 x 100 |
| Product Color | Black |
| Color Family | Black |
| Technical Information | |
| Aspect Ratio | 16:9 |
| Response Time | 10 ms |
| Features | Landscape/Portrait Viewable |
| Cable Lock Slot | |
| On-screen Display (OSD) | |
| Security Lock | |
| Anti-glare | |
| Mount Type | Wall Mountable |
| Pole Mount | |
| Viewable Screen Size | 15.6" |
| Screen Mode | HD |
| Placement | Tabletop |
| Horizontal Viewing Angle | 90° |
| Vertical Viewing Angle | 65° |
| Backlight Technology | LED |
| Panel Technology | Thin Film Transistor (TFT) |
| Horizontal Frequency | 31.50 Hz to 60 Hz |
| Curved Screen | No |
| Vertical Frequency | 60 Hz |
| Screen Size Class | 16" |
| Number of OSD Languages | 8 |
| Supported Graphics Resolutions | 800x600 (SVGA) |
| 640x480 (VGA) | |
| 1360 x 768 (WXGA) | |
| 1280 x 800 (WXGA) | |
| 1280 x 720 (HD 720) | |
| 1024 x 768 (XGA) | |
| 1280 x 1024 (SXGA) | |
| Stand Adjustments | Height |
