À propos du produit
Ultra-Rugged Cordless Area-Imaging Scanner
Granit Ultra scanners expand capabilities and define the next generation of ultra-rugged scanning.
ULTRA SCAN PERFORMANCE
For a scanner to optimize productivity, it should read and transmit common barcodes nearly as fast as the user can pull the trigger, and Granit Ultra is engineered to do just that. Damaged or low-quality printed barcodes can cause scanners' pace to decrease, or even force cumbersome (and error-prone) manual data entry. To maximize throughput, scanners must successfully compensate for poor code quality before scan delays put pressure on production.
Granit Ultra integrates high speed processing, AI algorithms, and decoding enhancements to result in an average 45% scanning speed increase vs. Granit XP*, enabling improved productivity. SR models are ready for action, reading barcodes from contact to arm's length.
ULTRA DURABILITY
In modern warehouse, distribution center, and manufacturing environments, any scanner must be durable enough to survive harsh operating conditions and powerful enough to capture and transmit barcode data without slowing workflows. Under exactly that kind of rough treatment, Granit is ready to deliver. 10' drops from fork trucks, docks, and picking trucks, 7,500 1-meter tumbles from normal working height, and wide operating temperatures are no problem.
But great specs are meaningless if there are other weak links in the chain. For instance, customers often cite scratched and broken scan windows as a frequent failure point in competitive scanners. Honeywell Granit Ultra's small, deeply recessed, scratch- and impact-resistant scan window is designed to address this, helping ensure that the electronics and optics remain IP65/68 protected. The new charge and communication base is tested to 500,000 insertion cycles, and recessed charge contacts help protect this critical component from potential impacts.
Spécifications techniques
| Network & Communication | |
| Bluetooth | Yes |
| Radio Frequency | Yes |
| Power Description | |
| Standby Current | 120 mA |
| Maximum Operating Power Consumption | 5 W |
| Battery Information | |
| Battery Chemistry | Lithium Ion (Li-Ion) |
| Battery Capacity | 3300 mAh |
| Maximum Battery Run Time | 14 Hour |
| Miscellaneous | |
| Application/Usage | Distribution |
| Manufacturing | |
| Warehouse | |
| Ingress Protection (IP) Rating | IP68 |
| IP65 | |
| General Information | |
| Product Type | Barcode Scanner |
| Manufacturer Part Number | 2105ISR-3USB-CLHN |
| Manufacturer Website Address | http://www.honeywell.com |
| Manufacturer | Honeywell International, Inc |
| Product Model | 2105iSR |
| Product Name | Granit Ultra 2105iSR Ultra-Rugged Cordless Area-Imaging Scanner |
| Product Line | Granit Ultra |
| Brand Name | Honeywell |
| Physical Characteristics | |
| Weight (Approximate) | 14.99 oz (425 g) |
| Durability | Impact Resistant |
| Scratch Resistant | |
| Form Factor | Handheld |
| Length | 7.67" (194.80 mm) |
| Height | 5.49" (139.50 mm) |
| Width | 2.99" (76 mm) |
| Rugged | Yes |
| Technical Information | |
| Barcode Symbology Supported |
|
| Connectivity Technology | Wireless |
| Features | Vibration |
| Notification LED | |
| Ergonomic Design | |
| Data Formatter | |
| Beep | |
| Scanning Distance | 40.67" (1033.02 mm) |
| Scanner Range | Standard Range |
| Drop Specification |
|
| Scan Pattern | Area |
| Image Sensor Type | Imager |
| Scan Mode | Trigger |
| Scanning Capability | 2D |
| 1D | |
| Field of View (Horizontal) | 40° |
| Field of View (Vertical) | 30° |
| Reading Angle (Skew) | 60° |
| Reading Angle (Pitch) | 45° |
| Reading Angle (Roll) | 360° |
| Motion Tolerance | 177 in/s (4495.80 mm/s) |
| Maximum Ambient Light | 100000 lux |
| Minimum Print Contrast | 15% |
| Minimum Element Resolution (Code 39) | 5 mil (0.13 mm) |
| Minimum Element Resolution (DataMatrix) | 10 mil (0.25 mm) |
| Minimum Element Resolution (PDF417) | 6.70 mil (0.17 mm) |
| Air Electrostatic Discharge (+/-) | 20kV |
| Contact Electrostatic Discharge (+/-) | 8kV |
| Image Sensor Resolution | 1280 x 800 |
| AI-powered | Yes |
