D-Link's 100G QSFP28 Module series are hot-swappable QSFP28 transceivers that plug into QSFP28 slots on switches and support 100G Ethernet. The D-Link 100GBase QSFP28 Module Series transceivers offer customers a wide variety of 100G Ethernet connectivity options for data centers, enterprise wiring closets, and service provider transport applications.
Quad Small Form-factor Pluggable 28 Format
The transceivers use the Quad Small Form-factor Pluggable 28 format (QSFP28) connectors, which integrate four independent transmitting and receiving channels. QSFP28 supports up to 25 Gb/s per channel for applications such as 100G Ethernet.
Hot-Pluggable
All D-Link transceivers are hot-pluggable. Hot-swap capability allows network administrators to plug or unplug it from the SFP slot without having to turn off the power of the connected device.
100G Ethernet speeds
The transceivers support 100G Ethernet, which results in very fast data transmissions of up to 100 Gbit/s, that enables the switches to handle fast and heavy data transmissions, making it suitable for business needs.
- Supports optical fiber cable for durable performance, minimal signal loss, and fast data transfers to greater distances
- 100 Gigabit Ethernet - High bandwidth performance, ease of use and reliable connectivity
- With a single wavelength of light, the single mode fiber optic can carry data and transmit audio/video applications over miles of distance
- With 100GBase-LR4 technology, get up to 100Gbps data transfer rate over optical fiber cable
Spécifications techniques
| Power Description | |
| Input Voltage | 3.3 V |
| Technical Information | |
| Application/Usage | Data Networking |
| Optical Network | |
| Interfaces/Ports | |
| Interfaces/Ports Details | 1 x LC Duplex 100GBase-LR4 Network |
| Connector Type | LC |
| Total Number of Ports | 1 |
| Miscellaneous | |
| Compatibility | MSA Compliant |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Physical Characteristics | |
| Form Factor | Hot-swappable |
| Hot-pluggable | |
| Height | 0.33" (8.50 mm) |
| Width | 0.72" (18.30 mm) |
| Depth | 2.76" (70 mm) |
| General Information | |
| Product Type | QSFP28 |
| Manufacturer Part Number | DEMQ2810QLR4 |
| Manufacturer Website Address | http://www.dlink.com |
| Manufacturer | D-Link Systems, Inc |
| Product Name | 100GBase-LR4 Single-Mode QSFP28 transceiver (up to 10 km) |
| Brand Name | D-Link |
| Media & Performance | |
| Maximum Distance Supported | 10 km |
| Network Technology | 100GBase-LR4 |
| Maximum Data Transfer Rate | 100 Gbit/s |
| Ethernet Technology | 100 Gigabit Ethernet |
| Media Type Supported | Optical Fiber |
| Fiber Mode Supported | Single-mode |
