System Component

Expected delivery 3 to 7 business days (exceptions applied)

Advantech

SERVEUR DE PÉRIPHÉRIQUES SÉRIE À 2 PORTS AVEC LARGE TEMPÉRATURE.

SERVEUR DE PÉRIPHÉRIQUES SÉRIE À 2 PORTS AVEC LARGE TEMPÉRATURE.

Prix habituel $680.39 CAD
Prix habituel $762.03 CAD Prix promotionnel $680.39 CAD
-10% OFF Épuisé
Frais d'expédition calculés à l'étape de paiement.
Serveur de périphériques série Advantech 2 ports RS-232/422/485 - Plage de températures étendue - Paire torsadée - 2 ports réseau (RJ-45) - 2 ports série - 10/100Base-TX - Fast Ethernet - Montage mural, montage sur rail DIN

VPN : EKI-1522I-CE SKU : RSC872299 CUP :

  • Fournit 2 ports Ethernet 10/100 Mbps pour la redondance LAN
  • Fournit la redirection de port COM (COM virtuel), les modes de fonctionnement TCP et UDP
  • Prend en charge jusqu'à 921,6 kbps et n'importe quel réglage de débit en bauds

Bloc de texte

Remise sur volume disponible - Demandez un devis.

Afficher tous les détails

Recently Viewed

SERVEUR DE PÉRIPHÉRIQUES SÉRIE À 2 PORTS AVEC LARGE TEMPÉRATURE.

Résumé des informations sur le produit

SERVEUR DE PÉRIPHÉRIQUES SÉRIE À 2 PORTS AVEC LARGE TEMPÉRATURE.

À propos du produit

EKI-1521, EKI-1522 and EKI-1524 feature two independent Ethernet ports and MAC addresses to provide a redundant network mechanism to guarantee Ethernet network reliability. EKI-1521, EKI-1522 and EKI-1524 are serial device servers that connect RS-232/422/485 serial devices, such as PLC, meters, sensors, and barcode reader to an IP-based Ethernet LAN. They allow nearly any device with serial ports to connect and share an Ethernet network. EKI-1521, EKI-1522 and EKI-1524 provide various operations: COM port redirection (Virtual COMport), TCP Server, TCP Client and UDP mode. With COM port redirection mode, standard serial operation calls are transparently redirected to the EKI-1521, EKI-1522 and EKI-1524, guaranteeing compatibility with legacy serial devices and enabling backward compatibility with existing software. With TCP server, TCP client, and UDP modes, EKI-1521, EKI-1522 and EKI-1524 ensure the compatibility of network software that uses a standard network API. Moreover, you can make serial devices communicate with other devices peer-to-peer, without any intermediate host PCs and software programming.

  • Provides 2 x 10/100 Mbps Ethernet ports for LAN redundancy
  • Provides COM port redirection (Virtual COM), TCP and UDP operation modes
  • Supports up to 921.6 kbps, and any baud rate setting
  • Allows a max. of 5 hosts to access one serial port
  • Allows a max. of 16 hosts to be accessed as TCP client mode
  • Built-in 15 KV ESD protection for all serial signals
  • Provides multiple configuration methods including Windows utility, Telnet console, and Web Browser
  • Supports 32-bit/64-bit Windows 2000/XP/Vista/7/8/8.1/10, Windows Server2003/2008/2012/2016, and Linux
  • Automatic RS-485 data flow control
  • Supports surge protection for D.C. power ports with line to line 2 KV, and line to earth 4 KV; for signal ports with 4 KV

Spécifications techniques

Media & Performance
Media Type SupportedTwisted Pair
Power Description
Power Consumption3.20 W
Network & Communication
Network Standard10/100Base-TX
Ethernet TechnologyFast Ethernet
Interfaces/Ports
Number of Network (RJ-45) Ports2
Network (RJ-45)Yes
Serial PortYes
Number of Serial Ports2
Miscellaneous
Certifications & Standards
  • EMC: CE, FCC
  • EMI: EN 55011/ EN 55032 Class A, EN 61000-6-4, FCC Part 15 Subpart B Class A
  • EMS: EN 61000-4-2 (Level 4), EN 61000-4-3 (Level 3), EN 61000-4-4 (Level 4), EN 61000-4-5 (Level 4), EN 61000-4-6 (Level 3), EN 61000-4-8 (Level 4), EN55024
  • Freefall: IEC 60068-2-32
  • Safety: UL 60950-1
  • Shock: IEC 60068-2-27
  • Vibration: IEC 60068-2-6
Country of OriginTaiwan
Environmentally FriendlyYes
Environmental ComplianceRestriction of Hazardous Substances (RoHS)
Physical Characteristics
Weight (Approximate)1.06 lb (480 g)
Form FactorDIN Rail Mountable
Wall Mountable
Height5.51" (140 mm)
Width1.44" (36.60 mm)
Depth3.74" (95 mm)
General Information
Product TypeDevice Server
Manufacturer Part NumberEKI-1522I-CE
Manufacturer Website Addresshttp://www.advantech.com
Packaged Quantity1
ManufacturerAdvantech Co., Ltd
Product ModelEKI-1522I
Product Name2-port RS-232/422/485 Serial Device Server - Wide Temperature
Brand NameAdvantech
