The IOGEAR 8-port USB Dual Link DVI KVMP Switch is a control unit that allows access and control of up to 8 computers from a single USB keyboard, USB mouse, and either a DVI or VGA monitor console. It can be cascaded to three levels - allowing up to 73 GCS1208s to control up to 512 computers - all from the original single console. In addition, GCS1208 comes with IOGEAR's Video DynaSync™ technology to optimize the display resolution. IOGEAR's DynaSync technology reads and remembers the monitor's parameters (EDID) so there is no delay or change of video resolution when switching between, or booting computers.
Switching between computers can be easily accomplished either by manually pressing the front panel push buttons, entering hotkey combinations from the keyboard, or via on-screen display (OSD) system. A convenient auto-scan feature permits automatic scanning and monitoring of activities on all connected.
- One USB console controls eight DVI or VGA computers
- Supports both digital (DVI), analog (DVI) video and analog (VGA)
- Superior video quality: 2560x1600 (Dual Link DVI), 1920x1200 (Single Link DVI), 2048x1536 (VGA); DDC2
- Supports widescreen resolutions
- Multiplatform support - Windows, Linux, Mac, Sun
- Computer selection via front panel pushbuttons, hotkeys, and on-screen display (OSD)
- Includes two USB 2.0 peripheral sharing ports
- Independent switching of KVM and USB focus
- Two-level (Administrator / User) password authorization for enhanced security protection
- Cascadable to three levels - control up to 512 computers
Spécifications techniques
| Video | |
| Maximum Video Resolution | 2560 x 1600 |
| Graphic Mode | WQXGA |
| Technical Information | |
| Number of Computers Supported | 8 |
| Number of Local Users Supported | 1 |
| Daisy Chain Supported | Yes |
| Physical Characteristics | |
| Weight (Approximate) | 2.90 kg |
| Height | 1.75" (44.45 mm) |
| Width | 17.20" (436.88 mm) |
| Depth | 6.30" (160.02 mm) |
| Miscellaneous | |
| Package Contents |
|
| Platform Supported | Mac |
| Sun | |
| PC | |
| Country of Origin | Taiwan |
| Interfaces/Ports | |
| Microphone | Yes |
| USB | Yes |
| DVI | Yes |
| VGA | Yes |
| Number of USB Ports | 10 |
| Number of VGA Ports | 1 |
| Number of DVI Ports | 9 |
| General Information | |
| Product Type | KM Switchbox |
| Manufacturer Part Number | GCS1208 |
| Manufacturer Website Address | http://www.iogear.com |
| Packaged Quantity | 1 |
| Manufacturer | IOGEAR, Inc |
| Product Model | GCS1208 |
| Product Name | 8-Port Dual Link DVI KVMP with VGA Support |
| Brand Name | IOGEAR |
