Cisco DNA Traffic Telemetry Appliance

Cisco DNA Traffic Telemetry Appliance

$25,614.20 CAD
$25,614.20 CAD
-Liquid error (snippets/price line 128): divided by 0% OFF Épuisé
Cisco DNA Traffic Telemetry Appliance

VPN:DN-APL-TTA-M SKU:ITM155063 UPC:

Loading

Volume discount available - Ask for quote..

Afficher tous les détails

Recently Viewed

Cisco DNA Traffic Telemetry Appliance

Résumé des informations sur le produit

Cisco DNA Traffic Telemetry Appliance

À propos du produit

Loading

Spécifications techniques

Miscellaneous
Additional Information
  • Default Memory: 16-GB DRAM
  • Processor: Integrated in the chassis: Intel 1.8GHz Quad Core Processor
  • Network and management I/O:
    • Supported connectors:
      • One RJ-45 10/100/1000 management Ethernet port
      • One RJ-45/RS-232 compatible console port
      • One Mini-USB serial console port
      • One RJ-45/RS-232 compatible auxiliary port
      • Two USB 2.0 connectors
  • Gigabit Ethernet ports:
    • Yes: Six 1G SFP ports
  • 10 Gigabit Ethernet port:
    • Yes: Two 10G SFP+ ports
    • Note: Built-in 10G ports cannot be reduced to 1G speed.
  • Network interface module: Yes, Only for SSD cards
  • Wall-mounting: No
  • External USB flash memory: 1-GB USB flash-memory support
  • Redundant power supply: Yes: Dual power supplies by default; option of either AC or DC power supply
  • Power input:
    • Worldwide ranging AC input range (85 to 264 VAC)
    • Worldwide ranging DC (-40 to -72V; 48V nominal)
  • Power consumption:
    • Maximum (DC): 242W
    • Maximum (AC): 250W
    • Maximum (out): 250W
  • Airflow: Front to back
  • Operating temperature (nominal): 32 to 104°F (0 to 40°C)
  • Operating temperature (short-term): 32 to 122°F (0 to 50°C)
  • Operating humidity (nominal) (relative humidity): 10% to 85%
  • Operating humidity (short-term): 5% to 90%
  • Storage temperature: -40° to 150°F (-40° to 70°C)
  • Storage humidity: (relative humidity) 5% to 95%
  • Operating altitude: -500 to 10,000 feet (-152 to 3048 meters)
  • Network Equipment Building Standards (NEBS): GR-1089 and GR-63
  • EMC standards:
    • FCC 47 CFR Part 15 Class A
    • VCCI Class A
    • AS/NSZ Class A
    • CES-003 Class A
    • EN55022/CISPR 22 Information Technology Equipment (Emissions)
    • EN55024/CISPR 24 Information Technology Equipment (Immunity)
    • EN300 386 Telecommunications Network Equipment (EMC)
    • EN50082-1/EN61000-6-1 Generic Immunity Standard
  • Safety Standard:
    • UL60950-1
    • CSA C22.2 No. 60950-1-03
    • EN 60950-1
    • IEC 60950-1
    • AS/NZS 60950.1
Application/UsageNetwork Monitoring
Physical Characteristics
Weight (Approximate)11.34 kg
Form FactorRack-mountable
Height1.71" (43.43 mm)
Width17.30" (439.42 mm)
Depth18.17" (461.52 mm)
General Information
Product TypeNetwork Monitoring Appliance
Manufacturer Part NumberDN-APL-TTA-M
Manufacturer Website Addresshttp://www.cisco.com
ManufacturerCisco Systems, Inc
Product ModelDN-APL-TTA-M
Product NameDNA Traffic Telemetry Appliance
Brand NameCisco
