À propos du produit
La gamme de commutateurs Aruba 2930M est conçue pour les espaces de travail numériques optimisés pour les utilisateurs mobiles. Ces puissants commutateurs d'accès de couche 3 sont faciles à déployer et à gérer grâce à des outils avancés de sécurité et de gestion réseau comme Aruba ClearPass Policy Manager, Aruba AirWave et Aruba Central basé sur le cloud. L'empilage modulaire, les liaisons montantes et l'alimentation offrent évolutivité et simplicité pour les réseaux d'entreprise, de PME et de succursales. Le 2930M offre performances et valeur ajoutée grâce à la prise en charge du routage statique, RIP et Access OSPF, des liaisons montantes 10 GbE et 40 GbE, des modèles avec 24 ports Ethernet multi-gigabit HPE Smart Rate, jusqu'à 1 440 W de PoE, une qualité de service robuste et une segmentation dynamique pour un accès unifié et sécurisé.
Spécifications techniques
| Primary Information | |
| Network Device Type: | Switch |
| Model: | Aruba 2930M Switch Series |
| Connectivity Technology: | Wired/Wireless |
| Data Transfer Rate: | 1 Gbps |
| Networking / Ports Qty: | 48 |
| Data Link Protocol: | Gigabit Ethernet |
| VLAN IP interfaces: | VLAN Support and Tagging supports IEEE 802.1Q (4094 VLAN IDs) and 2K VLANs simultaneously |
| Processor / Type: | ARM Cortex A9 |
| RAM / Total Installed Size: | 1 GB |
| Flash Memory / Installed Size: | 4 GB |
| Networking Compliant Standards: | IEEE 802.3 Type 10BASE-T,IEEE 802.3u Type 100BASETX,IEEE 802.3ab Type 1000Base-T,IEEE 802.3at PoE+ |
| Power / Device Type: | Power Supply |
| Power Consumption Operational: | 470 Watt |
| Max Power Consumption: | 2 Watt |
| Power / Voltage Required: | 100 - 127 / 200 - 240 VAC, rated or 110-127 / 200-240VAC, Rated depending on power supply |
| Network | |
| Power Over Ethernet (PoE) Support: | IEEE 802.3at Power over Ethernet (PoE+) provides up to 30 W per port that allows support of the latest PoE+-capable devices such as IP phones, wireless access points, and security cameras, as well as any IEEE 802.3af-compliant end device; eliminates the cost of additional electrical cabling and circuits that would otherwise be necessary in IP phone and WLAN deployments |
| PoE Power Consumption: | Up to 1440 Watts |
| MAC Address Table Size: | 32768 entries |
| Jumbo Frame Support: | Jumbo packet support improves the performance of large data transfers; supports frame size of up to 9220 bytes |
| Remote Management Protocol: | SNMP |
| Routing Protocol: | Layer 3 Dynamic |
| Encryption Algorithm: | MD5 |
| Authentication Method: | Uses an IEEE 802.1X supplicant on the client in conjunction with a RADIUS server to authenticate in accordance with industry standards; Supports web-based authentication; Supports MAC-based client authentication |
| 10/100/1000BASE-T Ports: | 44 |
| Interfaces: | (44) RJ-45 autosensing 10/100/1000 PoE+ ports (4) Dual Personality 10/100/1000 BASE-T PoE+ or 100/1000 Mbps SFP Ports (1) uplink module slot, (1) stacking module slot |
| Interfaces / Ports | |
| Interfaces: | (44) RJ-45 autosensing 10/100/1000 PoE+ ports (4) Dual Personality 10/100/1000 BASE-T PoE+ or 100/1000 Mbps SFP Ports (1) uplink module slot, (1) stacking module slot |
| VLAN IP interfaces: | VLAN Support and Tagging supports IEEE 802.1Q (4094 VLAN IDs) and 2K VLANs simultaneously |
| 10/100/1000BASE-T Ports: | 44 |
| Dimensions&Miscellaneous | |
| Width: | 1.73 Inch |
| Depth: | 17.42 Inch |
| Height: | 12.77 Inch |
| Weight: | 10.25 lbs. |
| Service&Support | |
| Service & Support Type: | Limited Lifetime Warranty |
| Special Feature | |
| Min Operating Temperature: | 0 Celsius(up to 5000 Feet) |
| Max Operating Temperature: | 55 Celsius |
| Min Storage Temperature: | -40 Celsius(up to 15000 Feet) |
| Max Storage Temperature: | 70 Celsius |
| COO: | Inquire |
| TAA compliance: | Inquire |
| UNSPSC Code | |
| UNSPSC Code: | 43222612 |
