À propos du produit
Manage multiple servers with just one keyboard, monitor and mouse.
- Use this KVM Switchbox and eliminate the need for manually switching cables between sources
- Switch between sources by using this KVM Switchbox without degradation of performance and eliminate the manual work
- Quickly switches between sources without physical access
- Let you connect 16 computers to 1 local users
- Get reliable connectivity between 16 computers and 1 local users
- Enjoy watching any class of content on 1600 x 1200 resolution
- Features 1600 x 1200 resolution
- USB port for easy connectivity
- Unhindered connections with USB-compatible devices are ensured by the built-in USB port.
- KVM Switchbox can be mounted as rack-mountable
- Designed to be used as a rack-mountable
Spécifications techniques
| Power Description | |
| Input Voltage | 240 V |
| Warranty | |
| Additional Warranty Information | 2 years repair or replace |
| Video | |
| Maximum Video Resolution | 1600 x 1200 |
| Graphic Mode | UXGA |
| Technical Information | |
| KVM Technology | Analog |
| Number of Computers Supported | 16 |
| Number of Local Users Supported | 1 |
| General Information | |
| Product Type | KVM Switchbox |
| Manufacturer Part Number | KVM0116A |
| Manufacturer Website Address | http://www.schneider-electric.com |
| Packaged Quantity | 1 Each |
| Manufacturer | Schneider Electric SA |
| Product Name | KVM 2G, Analog, 1 Local User, 16 ports |
| Brand Name | APC by Schneider Electric |
| Interfaces/Ports | |
| USB | Yes |
| VGA | Yes |
| Number of Network (RJ-45) Ports | 16 |
| Network (RJ-45) | Yes |
| Number of USB Ports | 2 |
| Management Port | Yes |
| PS/2 Port | Yes |
| Number of PS/2 Ports | 2 |
| Number of VGA Ports | 1 |
| Physical Characteristics | |
| Weight (Approximate) | 5.29 lb (2399.50 g) |
| Form Factor | Rack-mountable |
| Rack Height | 1U |
| Height | 1.69" (43 mm) |
| Width | 16.69" (424 mm) |
| Depth | 7.40" (188 mm) |
| Product Color | Black |
| Color Family | Black |
| Mounting Location | Front |
| Mounting Preference | No Preference |
| Miscellaneous | |
| Certifications & Standards | cUL Listed|C-tick|CE|EAC|TAA compliance|UL-AR|VCCI Class A|VDE |
| Country of Origin | Taiwan |
| Environmentally Friendly | Yes |
| Mercury Free | Yes |
| For Country/Region | United States |
| Product Take Back Program | No |
| RoHS Exemption Information | https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=KVM0116A_ROHS_DECLARATION&p_FileName=KVM0116AKIT_ROHS_DECLARATION_US.pdf |
| REACH Declaration URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=323195092&lang=en-us |
| EU RoHS Declaration URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=323195092&lang=en-us |
| End of Life Manual Availability | https://download.schneider-electric.com/files?p_enDocType=Circularity+Profile&p_Doc_Ref=ENVEOLI1512008_EN |
| REACH free of SVHC | Yes |
| WEEE Statement | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
