À propos du produit
Manage multiple servers with just one keyboard, monitor and mouse.
- Use this KVM Switchbox and eliminate the need for manually switching cables between sources
- Switch between sources by using this KVM Switchbox without degradation of performance and eliminate the manual work
- With this KVM Switchbox, avoid the constant switching of cables between sources
- Connect up to 16 computers to 1 local users
- Switch between 16 computers and 1 local users
- Let you connect 16 computers to 1 local users
- USB port for easy connectivity
- Establishes a rapid connection with USB devices
- The Built-in USB port enables easy connection with USB-compatible devices
- The rack-mountable form factor provides convenient installation
- KVM Switchbox can be mounted as rack-mountable
- The Rack-mountable form factor allocates you simple and easy installation for your kvm switchbox
- Designed to be used as a rack-mountable
Spécifications techniques
| Warranty | |
| Additional Warranty Information | 2 years repair or replace |
| Technical Information | |
| Maximum Operating Distance | 9842.52 ft (3000000 mm) |
| Number of Computers Supported | 16 |
| Number of Local Users Supported | 1 |
| Number of Remote Users Supported | 1 |
| General Information | |
| Product Type | KVM Switchbox |
| Manufacturer Part Number | KVM1116R |
| Manufacturer Website Address | http://www.schneider-electric.com |
| Manufacturer | Schneider Electric SA |
| Product Model | KVM1116R |
| Product Name | KVM1116R KVM Switchbox |
| Brand Name | APC by Schneider Electric |
| Power Description | |
| Input Voltage | 230 V |
| 120 V | |
| 240 V | |
| 24 V DC | |
| 208 V | |
| 100 V | |
| Input Voltage Range | 120V AC to 230V AC |
| Interfaces/Ports | |
| USB | Yes |
| VGA | Yes |
| Number of Network (RJ-45) Ports | 20 |
| Network (RJ-45) | Yes |
| Number of USB Ports | 5 |
| PS/2 Port | Yes |
| Number of PS/2 Ports | 2 |
| Number of VGA Ports | 1 |
| Physical Characteristics | |
| Weight (Approximate) | 5.71 lb (2590.01 g) |
| Form Factor | Rack-mountable |
| Rack Height | 1U |
| Height | 1.69" (43 mm) |
| Width | 16.69" (424 mm) |
| Depth | 7.40" (188 mm) |
| Mounting Location | Front |
| Mounting Preference | No Preference |
| Miscellaneous | |
| Certifications & Standards | C-tick|CE|EAC|TAA compliance|UL-AR|VCCI Class A|VDE |
| Country of Origin | Philippines |
| Environmentally Friendly | Yes |
| Mercury Free | Yes |
| For Country/Region | United States |
| Product Take Back Program | No |
| RoHS Exemption Information | https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=KVM1116R_ROHS_DECLARATION&p_FileName=KVM1116RKIT_ROHS_DECLARATION_US.pdf |
| REACH Declaration URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=490326837&lang=en-us |
| EU RoHS Declaration URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=490326837&lang=en-us |
| End of Life Manual Availability | https://download.schneider-electric.com/files?p_enDocType=Circularity+Profile&p_Doc_Ref=ENVEOLI1512008_EN |
| REACH free of SVHC | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
