À propos du produit
Leviton 2nd Gen Smart Circuit Breakers give you unmatched control over your Leviton Load Centre by enabling you to remotely turn on and off circuits or to set up a schedule through the My Leviton app. Leviton 2nd Gen Smart Circuit Breakers are the smart answer for your home's electrical system when paired with real-time energy consumption data, historical graphs, anomaly detection, notifications, and remote firmware updates.
Leviton 2nd Gen Smart Circuit Breakers with Remote Control can be set as absolutely necessary or not necessary for situations involving Automatic Transfer Switches. Any loads set up as non-essential will be removed automatically when the backup generator kicks in. If a suitable generator powers a Leviton load centre, controlling high-current loads using 2nd Gen Smart Circuit Breakers can avoid the requirement for a supplementary Essential Loads Panel.
With 2nd Generation Smart Circuit Breakers, homeowners can easily and affordably reduce excessive usage and save money by remotely scheduling and managing circuits.
Make a plan to switch off your hot water heater at night, or remotely shut off the circuit that supplies your high-current pump when you're away.
Leviton 50A 2-POLE Smart Breaker, 2nd Gen Features and Benefits:
- Smart: Easily access your 2nd Gen Smart Circuit Breakers with Remote Control and home’s energy data via smartphone, tablet, or desktop in the My Leviton app
- Simple: Features an all plug-on installation - no wiring to circuit breakers up to 60A for copper wire, and 50A for aluminum wire
- Intuitive: Line-side powered LEDs stay lit, even after a circuit breaker has tripped, and identify cause of trip. Color indicators in each rocker handle designate operational status at-a-glance (ON/OFF/Tripped)
- Scheduling: Select breakers can automatically turn ON or OFF based on a predefined schedule
- Control: Remotely turn circuit breakers ON or OFF
- Monitor: View real-time energy consumption in the My Leviton app: total aggregate, individual circuit, or trends by day, week, month, and year
- Flexible: Can be installed in any Leviton Load Center. Upgrading to a Smart Load Center is as easy as prioritizing which loads to enable with smart capabilities, pulling the old breakers out, snapping the new 2nd Gen Smart Circuit Breakers with Remote Control in their place, and enrolling them to the My Leviton app
Leviton 50A 2-POLE Smart Breaker, 2nd Gen Specifications:
- Dimensions:
- Single Pole 3.9” H x 1.0” W x 3.1” D
- Double Pole 3.9” H x 2.0” W x 3.1” D
- Operating Temperature: -40°C to 70°C (-40°F to 158°F)
- Warranty: 10-Year Limited, 2-Years for electronic components
- Weight: Single Pole 0.42 lbs.
- Double Pole 0.85 lbs.
- Wiring: All Plug-on up to 60A for Cu wire, 50A for Al wire
- Electrical Specifications:
- Amperage: Refer to catalog number tables
- Short Circuit Current Rating: 10 KA, Series Rated 22KA with Leviton Main Breaker; see Series Ratings Tables for additional Ratings
- Type: Available in Standard, AFCI, GFCI, AFCI/GFCI, GFPE
- Standards & Certifications:
- CSA-C22.2 No. 5-02
- EMC Compatible
- FCC
- RoHS
- UL 489, HACR rated
- UL 943 (GFCI), where applicable
- UL1699 (AFCI), where applicable
Spécifications techniques
Leviton 2nd Gen Smart Circuit Breakers give you unmatched control over your Leviton Load Centre by enabling you to remotely turn on and off circuits or to set up a schedule through the My Leviton app. Leviton 2nd Gen Smart Circuit Breakers are the smart answer for your home's electrical system when paired with real-time energy consumption data, historical graphs, anomaly detection, notifications, and remote firmware updates.
Leviton 2nd Gen Smart Circuit Breakers with Remote Control can be set as absolutely necessary or not necessary for situations involving Automatic Transfer Switches. Any loads set up as non-essential will be removed automatically when the backup generator kicks in. If a suitable generator powers a Leviton load centre, controlling high-current loads using 2nd Gen Smart Circuit Breakers can avoid the requirement for a supplementary Essential Loads Panel.
With 2nd Generation Smart Circuit Breakers, homeowners can easily and affordably reduce excessive usage and save money by remotely scheduling and managing circuits.
Make a plan to switch off your hot water heater at night, or remotely shut off the circuit that supplies your high-current pump when you're away.
Leviton 50A 2-POLE Smart Breaker, 2nd Gen Features and Benefits:
- Smart: Easily access your 2nd Gen Smart Circuit Breakers with Remote Control and home’s energy data via smartphone, tablet, or desktop in the My Leviton app
- Simple: Features an all plug-on installation - no wiring to circuit breakers up to 60A for copper wire, and 50A for aluminum wire
- Intuitive: Line-side powered LEDs stay lit, even after a circuit breaker has tripped, and identify cause of trip. Color indicators in each rocker handle designate operational status at-a-glance (ON/OFF/Tripped)
- Scheduling: Select breakers can automatically turn ON or OFF based on a predefined schedule
- Control: Remotely turn circuit breakers ON or OFF
- Monitor: View real-time energy consumption in the My Leviton app: total aggregate, individual circuit, or trends by day, week, month, and year
- Flexible: Can be installed in any Leviton Load Center. Upgrading to a Smart Load Center is as easy as prioritizing which loads to enable with smart capabilities, pulling the old breakers out, snapping the new 2nd Gen Smart Circuit Breakers with Remote Control in their place, and enrolling them to the My Leviton app
Leviton 50A 2-POLE Smart Breaker, 2nd Gen Specifications:
- Dimensions:
- Single Pole 3.9” H x 1.0” W x 3.1” D
- Double Pole 3.9” H x 2.0” W x 3.1” D
- Operating Temperature: -40°C to 70°C (-40°F to 158°F)
- Warranty: 10-Year Limited, 2-Years for electronic components
- Weight: Single Pole 0.42 lbs.
- Double Pole 0.85 lbs.
- Wiring: All Plug-on up to 60A for Cu wire, 50A for Al wire
- Electrical Specifications:
- Amperage: Refer to catalog number tables
- Short Circuit Current Rating: 10 KA, Series Rated 22KA with Leviton Main Breaker; see Series Ratings Tables for additional Ratings
- Type: Available in Standard, AFCI, GFCI, AFCI/GFCI, GFPE
- Standards & Certifications:
- CSA-C22.2 No. 5-02
- EMC Compatible
- FCC
- RoHS
- UL 489, HACR rated
- UL 943 (GFCI), where applicable
- UL1699 (AFCI), where applicable
