Low profile, low cost - for tight places and tight budgets
All of your applications have one thing in common, they need power. From HVAC to factory controls, from machinery to robotics, you need a power supply that meets all your requirement for wattage, voltage, and approvals, but still fits in your design. Finding all that in a single package can be a challenge. The solution is B&B Electronics' complete line of switching technology power supplies. No load power consumption less than 0.75W on 20-60W models. Check the features. Check the prices . You'll find one to meet your needs.
Spécifications techniques
| Reliability | |
| MTBF | 346000 Hour |
| Miscellaneous | |
| Certifications & Standards |
|
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Physical Characteristics | |
| Form Factor | DIN Rail |
| Height | 3.54" (90 mm) |
| Width | 2.17" (55 mm) |
| Depth | 3.94" (100 mm) |
| Technical Information | |
| Efficiency | 88% |
| Protection Type | Over Temperature |
| Over Voltage | |
| Overload | |
| Short Circuit | |
| General Information | |
| Product Type | Proprietary Power Supply |
| Manufacturer Part Number | MDR10048 |
| Manufacturer Website Address | http://www.advantech.com |
| Manufacturer | Advantech Co., Ltd |
| Product Model | MDR-100-48 |
| Product Name | 100W, 48VDC Industrial Slimline Power Supply |
| Product Series | MDR-100 |
| Brand Name | B+B SmartWorx |
| Power Description | |
| Input Voltage | 220 V AC |
| 110 V AC | |
| Output Power | 100 W |
| Output Voltage | 48 V DC |
| Input Current | 1.3 A @ 110V |
| 800 mA @ 220V | |
| Output Current | 2 A |
| Input Voltage Range | 85 V AC - 264 V AC |
| 120 V AC - 370 V AC | |
| Input Voltage Type | AC |
| Output Voltage Detail | 48 V DC @ 2 A |
