À propos du produit
NETGEAR Plus Switches with PoE meet business networks growing needs by providing fundamental network features such as simplified VLANs, QoS set-up and IGMP Snooping that will help optimize the performance of business networks. Plus Switches are the perfect upgrade from the plug-and-play unmanaged switch, delivering essential networking features at a very affordable price. The new model MS108EUP supports 2.5 Gigabit speed connectivity and Power-Over-Ethernet (PoE) that can provide up to 60W/port. The new switch model can power devices such as VoIP phones, surveillance IP cameras, wireless access points and many other applications. This new Plus switch includes advance PoE control to help optimize the performance and troubleshooting of business networks. The new and improved business- friendly GUI allows easy management and simple configuration. With the growing deployment of applications and an all-in-one solution, providing management and power to these applications would be ideal.
- 802.3bt standard offering up to 60W/ port on Port 1-4, 802.3at (30W/port) on Port 5-8
- 230W total PoE budget available across 8 ports.
- Simple set up with no software or configuration needed.
- Easy monitoring through per port LEDs for port activity and speed.
- Unique PoE Auto-Balance technology automatically balances the PoE power based on the device needs independent of PoE class detected. The switches deliver the power the device needs, at the most granular level.
- Energy Efficient Ethernet (IEEE 802.3az) support for maxium power savings.
- 8 ports of multi-gig 1G/2.5G speeds to connect devices instantly and give them each exactly the speed they need: 1G or 2.5G automatically.
- Non-blocking switching architecture for maximum throughput at wire speed
- Fanless, silent operation with desktop and rack-mounting options
- Lifetime 24/7 Chat Technical Support
Spécifications techniques
| Management & Protocols | |
| Manageable | No |
| Miscellaneous | |
| Package Contents |
|
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Total Number of Network Ports | 8 |
| Port/Expansion Slot Details | 8 x Gigabit Ethernet PoE++ |
| Media & Performance | |
| Network Technology | 2.5GBase-T |
| Ethernet Technology | 2.5 Gigabit Ethernet |
| Media Type Supported | Twisted Pair |
| Power Description | |
| Input Voltage | 54 V |
| Power Source | Power Adapter |
| Power Consumption | 270.50 W |
| Number of Power Supplies Installed | 1 |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 230 W |
| General Information | |
| Product Type | Ethernet Switch |
| Manufacturer Part Number | MS108UP-100NAS |
| Manufacturer Website Address | http://www.netgear.com |
| Manufacturer | Netgear, Inc |
| Product Model | MS108UP |
| Product Name | 8-port Ultra60 PoE++ Multi-Gigabit (2.5G) Ethernet Plus Switch |
| Brand Name | Netgear |
| Physical Characteristics | |
| Weight (Approximate) | 1.98 lb (900 g) |
| Form Factor | Wall Mountable |
| Desktop | |
| Height | 1.57" (40 mm) |
| Width | 8.27" (210 mm) |
| Depth | 5.51" (140 mm) |
| Product Color | Gray |
| Blue | |
| Color Family | Dual Color |
| Product Material | Metal |
| Network & Communication | |
| Layer Supported | 3 |
| Networking Standards | IEEE 802.3ab |
| IEEE 802.3ad | |
| IEEE 802.3 | |
| IEEE 802.1Q | |
| IEEE 802.1p | |
| IEEE 802.3u | |
| IEEE 802.3x | |
| IEEE 802.3bt | |
| IEEE 802.3af | |
| IEEE 802.3at | |
| IEEE 802.3az |
