À propos du produit
- Provide circuit protection and easy configuration for trouble-free access
- With a built-in digital current meter avoid potential overloads via switched PDUs
Spécifications techniques
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Management | |
| Management | SNMP |
| Environmental Conditions | |
| Minimum Operating Temperature | 50°F (10°C) |
| Maximum Operating Temperature | 140°F (60°C) |
| Minimum Storage Temperature | 24.8°F (-4°C) |
| Maximum Storage Temperature | 284°F (140°C) |
| Miscellaneous | |
| Package Contents |
|
| Certifications & Standards |
|
| Environmental Compliance | China Restriction of Hazardous Substances (China RoHS) |
| Restriction of Hazardous Substances (RoHS) | |
| Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) | |
| Power Description | |
| Circuit Breaker | Yes |
| Input Voltage | 415 V AC |
| Output Voltage | 240 V AC |
| Input Current | 20 A |
| Input Frequency | 60 Hz |
| Power Rating (Watt) | 11.50 kW |
| General Information | |
| Product Type | PDU |
| Manufacturer Part Number | P36G32G |
| Manufacturer Website Address | http://www.panduit.com |
| Packaged Quantity | 1 |
| Manufacturer | PANDUIT CORP |
| Product Name | G6 36-Outlets PDU |
| Product Series | G6 |
| Brand Name | Panduit |
| Physical Characteristics | |
| Mount Type | Rack-mountable |
| Rack Height | 38U |
| Cord Length | 10 ft (3.05 m) |
| Height | 66" (1676.40 mm) |
| Width | 2.30" (58.42 mm) |
| Depth | 2.90" (73.66 mm) |
| Mounting Orientation | Vertical |
| Product Color | Black |
| Color Family | Black |
| Technical Information | |
| Features | Onboard Display |
| Plug/Connector Type | IEC 60309 3P+N+E 6h (IP44) |
| Phase | Three Phase |
| Receptacle Type | IEC 60320 C13 |
| IEC 60320 C19 | |
| Load Capacity (Watt) | 11.50 kW |
| PDU Type | Monitored |
| Switched | |
| Receptacle Detail | 24 x IEC 60320 C13 |
| 12 x IEC 60320 C19 |
