Sous-station d'interphone vidéo 2N IP Force - CMOS - 135° Horizontal - 109° Vertical

Sous-station d'interphone vidéo 2N IP Force - CMOS - 135° Horizontal - 109° Vertical

Prix habituel $0.00 CAD
Prix habituel $0.00 CAD Prix promotionnel $0.00 CAD
-Liquid error (snippets/price line 128): divided by 0% OFF Épuisé
Frais d'expédition calculés à l'étape de paiement.
Sous-station d'interphone vidéo 2N IP Force - CMOS - 135° horizontal - 109° vertical - Full duplex - Aluminium - Caméra de vidéosurveillance, système de gestion vidéo (VMS)

VPN : 01334-001 SKU : PHS299682 CUP :

  • Conçu pour des conditions extrêmes
  • Vision nocturne professionnelle
  • Un son clair dans les environnements bruyants

Bloc de texte

Remise sur volume disponible - Demandez un devis.

Afficher tous les détails

Recently Viewed

Sous-station d'interphone vidéo 2N IP Force - CMOS - 135° Horizontal - 109° Vertical

Résumé des informations sur le produit

Sous-station d'interphone vidéo 2N IP Force - CMOS - 135° Horizontal - 109° Vertical

À propos du produit

TOUGHEST IP INTERCOM IN THE WORLD

2N® IP Force is an extremely durable IP intercom that can withstand even the most demanding conditions. It provides for visitor communication monitoring and access control. Take advantage of its superior features for maximum site security.

  • Built for extreme conditions
  • Professional night vision
  • Clear sound in noisy environments
  • Durable access control solution
  • Wide-angle HD camera
  • Easy integration into CCTV and VMS

Spécifications techniques

Power Description
Input Voltage12 V DC
Technical Information
Communication ModeFull-duplex
Camera
Horizontal Viewing Angle135°
Vertical Viewing Angle109°
Image Sensor TypeCMOS
Miscellaneous
Additional Information
  • Signalling Protocol: SIP (UDP, TCP, TLS)
  • Button:
    • Button design: Transparent, white backlit buttons with easily replaceable label
    • Count of buttons: 1
    • Numerical keypad: Optional
  • Audio:
    • Microphone: 2 integrated microphones
    • Amplifier: 10 W (class D)
    • Speaker: 10 W
    • Volume control: Adjustable with automatic adaptive mode
  • Audio Stream:
    • Protocols RTP/RTSP
    • Codecs G.711, G.722, G.729, L 16/16kHz
  • Camera HD:
    • JPEG resolution 1280 (H) x 960 (V)
    • Video resolution 640 (H) × 480 (V)
    • Frame rate Up to 30 snapshots/s
    • Sensor sensitivity: 5.6 V/lux-sec (550 nm) / 1.9 V/lux-sec (550 nm)
    • Infrared light: Yes
  • Video stream:
    • Protocols: RTP/RTSP/HTTP
    • Codecs: H.263, H.263+, H.264, MPEG-4, M-JPEG
    • IP camera function: Yes, ONVIF v2.4 profile S compatible
  • Interface:
    • PoE: PoE 802.3af (Class 0 - 12,95 W)
    • LAN: 10/100BASE-TX with Auto-MDIX, RJ-45
    • Recommended cabling: Cat-5e or higher
    • Passive switch: NO/NC contacts, max. 30 V/1A AC/DC
    • Active switch output: 9 up to 13 V DC depending on power supply, max. 700 mA
  • Mechanical Properties:
    • Operating temperature -40°F to 131 °F
    • Storage temperature -40 °F to 158 °F
    • humidity: 10 % - 95 % (non-condensing)
    • Covering level IP69K and IK10
  • RFID Card Reader:
    • Supported frequencies: 125kHz and 13.56MHz
    • 125 kHz: EM4100, EM4102, HID Proximity
    • 13.56 MHz: ISO14443A, ISO14443B, ISO15693, NFC support
    • reads UID (CSN)
    • reads PACs ID (iCLASS SIO-enabled cards) - only secured cards
Application/UsageVideo Management System (VMS)
CCTV Camera
Country of OriginCzech Republic
General Information
Product TypeVideo Door Phone Sub Station
Manufacturer Part Number01334-001
Manufacturer Website Addresshttp://www.axis.com
ManufacturerAxis Communications
Product NameIP Force Video Door Phone Sub Station
Product LineIP Force
Brand Name2N
Physical Characteristics
Weight (Approximate)4.41 lb (1999.89 g)
DurabilityWater Resistant
Height8.54" (216.99 mm)
Width4.29" (108.99 mm)
Depth3.27" (83.01 mm)
Product ColorBlack
Product MaterialAluminum
