Do you need an intercom to switch on lights or call a lift, but the switched devices are far away and laying cables all the way to the intercom isn't an option? Use an external IP relay, which is controlled using HTTP commands from a 2N IP intercom or access unit. The command is sent to the relay in unsecured form. You can also use the IP relay input. Connect an exit button, for example, to switch the output locally.
Spécifications techniques
| Power Description | |
| Minimum Operating Voltage | 9 V DC |
| Maximum Operating Voltage | 28 V DC |
| Product Information | |
| Application/Usage | Intercom System |
| Interface | RJ-45 |
| Miscellaneous | |
| Additional Information |
|
| Compatibility | 2N Products:
|
| Country of Origin | Czech Republic |
| Environmental Conditions | |
| Minimum Operating Temperature | -40°F (-40°C) |
| Maximum Operating Temperature | 134.6°F (57°C) |
| Minimum Storage Temperature | -40°F (-40°C) |
| Maximum Storage Temperature | 185°F (85°C) |
| Physical Characteristics | |
| Weight (Approximate) | 5.01 oz (142 g) |
| Height | 3.07" (78 mm) |
| Width | 1.42" (36 mm) |
| Product Material | Polycarbonate Plastic |
| General Information | |
| Product Type | Relay |
| Manufacturer Part Number | 01397-001 |
| Manufacturer Website Address | http://www.axis.com |
| Manufacturer | Axis Communications |
| Product Name | External IP Relay - 1 Output, 1 Input |
| Brand Name | AXIS |
