À propos du produit
The PR2200RTXL2UHVAN is a high voltage Smart App Sinewave rack/tower convertible UPS with line-interactive topology, surge protection, and battery backup. CyberPower's Smart App Sinewave series creates a sine wave output devoid of power gaps which could cause unexpected shutdowns of sensitive equipment.
The Smart App Sinewave PR2200RTXL2UHVAN improves battery life through battery equalization technology and Automatic Voltage Regulation (AVR), which corrects minor power fluctuations without switching to battery power. The enhanced chassis design with an easy-to-access toolless front panel, captive screws for battery panel access, and color-coded rear panel make battery changes and installations simple and fast. The PR2200RTXL2UHVAN also has an innovative LCD panel that rotates 90°, tilts for a better viewing angle, and provides information on 47 different settings including UPS stats, UPS setup and control management, and testing options.
This model accepts the BP48VP2U03 Extended Battery Module (EBM) for expanded runtime during power outages and includes pre-installed RMCARD205 network management card for remote management and control via a standard web browser or network management system.
With a $400,000 connected equipment guarantee and a three-year warranty, you can trust CyberPower's commitment to the quality of the PR2200RTXL2UHVAN.
- Capacity: 2200 VA / 2200 W
- Topology: Line Interactive
- Waveform: Sine Wave
- Output: 200-240 VAC ± 5%
- Plug type & cord: NEMA L6-20P, 10 ft. cord
- Outlet types: 4 × NEMA 6-20R; 2 x NEMA L6-20R
- Communication: USB, Serial, SNMP, Relay, EPO
- Management software: PowerPanel® Business Edition
- Remote management: Yes, pre-installed RMCARD205
- Warranty: 3 year
Spécifications techniques
| Controls/Indicators | |
| Status Indicators | Multifunction LCD Panel:
|
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Serial Port | Yes |
| EPO Port | Yes |
| USB (HID Compliant) Port | Yes |
| Environmental Conditions | |
| Thermal Dissipation | 83.10 BTU/h |
| Maximum Operating Temperature | 104°F (40°C) |
| Maximum Operating Elevation | 9842.52 ft (3000000 mm) |
| Maximum Storage Elevation | 49212.60 ft (15000000 mm) |
| Sound Emission (A-Weighted) | 57.5 dB(A) |
| Management | |
| Network Management | SNMP/HTTP Remote Monitoring |
| Alarm | Overload |
| Overheat | |
| Over Charge | |
| Low Battery | |
| Battery Mode | |
| Miscellaneous | |
| Additional Information |
|
| Software Included | PowerPanel® Business Edition |
| Certifications & Standards |
|
| Country of Origin | Philippines |
| Environmentally Friendly | Yes |
| Energy Star | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Physical Characteristics | |
| Weight (Approximate) | 92.59 lb (42000 g) |
| Form Factor | Rack/Tower |
| Rack Height | 2U |
| Height | 3.39" (86 mm) |
| Width | 17.09" (434 mm) |
| Depth | 24.80" (630 mm) |
| Product Color | Black |
| Color Family | Black |
| Battery Information | |
| Battery Chemistry | Lead Acid |
| Battery Size | 12V |
| Battery Capacity | 6000 mAh |
| Number of Batteries | 8 |
| Backup/Run Time (Half Load) | 15.20 Minute |
| Backup/Run Time (Full Load) | 5.30 Minute |
| Battery Characteristics | Sealed |
| Replaceable Battery | Yes |
| Typical Battery Recharge Time | 3 Hour |
| General Information | |
| Product Type | Line-interactive UPS |
| Manufacturer Part Number | PR2200RTXL2UHVAN |
| Manufacturer Website Address | https://www.cyberpowersystems.com/ |
| Manufacturer | CyberPower Systems, Inc |
| Product Model | PR2200RTXL2UHVAN |
| Product Name | Smart App Sinewave PR2200RTXL2UHVAN 2200VA Rack/Tower UPS |
| Product Series | New Smart App Sinewave UPS |
| Brand Name | CyberPower |
| Product Condition | New |
| Power Description | |
| Input Voltage | 230 V AC |
| Output Voltage | 200 V AC |
| 220 V AC | |
| 240 V AC | |
| 230 V AC | |
| 208 V AC | |
| Surge Energy Rating | 2430 J |
| Waveform Type | Sine Wave |
| Input Voltage Range | 131 V AC - 302 V AC |
| Output Frequency | 60 Hz |
| Input Frequency | 63 Hz |
| Load Capacity (VA) | 2.20 kVA |
| Technical Information | |
| Dataline Protection | RJ-45 |
| Overload Protection | Yes |
| Plug/Connector Type | NEMA L6-20P |
| Receptacle Type | NEMA L6-20R |
| NEMA 6-20R | |
| EMI/RFI Noise Filter | Yes |
| AVR | Yes |
| Energy Saving | GreenPower UPS™ Bypass Technology |
| Number of Battery & Surge Outlets | 6 |
| Number of Critical Load Outlets | 2 |
| Transfer Time | 4 ms |
| Receptacle Detail | 4 x NEMA 6-20R |
| 2 x NEMA L6-20R |
