À propos du produit
Exos® CORVAULT Self Healing Storage redefines petabyte-scale storage infrastructure with industry-leading innovation in every aspect of the system.
Reliable and Self-healing. Field-proven design with five-nines (99.999%) availability. Autonomous Drive Regeneration (ADR) reduces human intervention and e-waste by automatically renewing hard drives "in situ" and on the fly.
Hyperscale-class efficiencies. Combining maximum data density of up to 2.120 PB raw (using 20 TB drives) in 4U with the latest hard drive technology delivers storage efficiencies similar to cutting-edge cloud service providers.
Architected for speed and resilience. Redundant active-active controllers powered by the 6th gen VelosCT ASIC and ADAPT erasure code data protection software dramatically streamline overhead, throughput, management and recovery.
Powerful configuration and management. One-button configuration accelerates deployment, while informative remote diagnostics and non-disruptive system updates simplify maintenance.
Seagate Secure built in. Hard drives are self-encrypting (SED) for maximum security without controller-level overhead. SFTP for secure file transfer. Optional FIPS 140-3 configuration.
Key Advantages
Introducing a new category of intelligent storage. Exos CORVAULT delivers sophisticated data protection, security and streamlined management to tackle the challenges of an exascale world.Reliable and Self-healing. Field-proven design with five-nines (99.999%) availability. Autonomous Drive Regeneration (ADR) reduces human intervention and e-waste by automatically renewing hard drives "in situ" and on the fly.
Hyperscale-class efficiencies. Combining maximum data density of up to 2.120 PB raw (using 20 TB drives) in 4U with the latest hard drive technology delivers storage efficiencies similar to cutting-edge cloud service providers.
Architected for speed and resilience. Redundant active-active controllers powered by the 6th gen VelosCT ASIC and ADAPT erasure code data protection software dramatically streamline overhead, throughput, management and recovery.
Powerful configuration and management. One-button configuration accelerates deployment, while informative remote diagnostics and non-disruptive system updates simplify maintenance.
Seagate Secure built in. Hard drives are self-encrypting (SED) for maximum security without controller-level overhead. SFTP for secure file transfer. Optional FIPS 140-3 configuration.
- Effortlessly expand capacity with up to 2.120 PB raw (using 20 TB drives) in a maximum-density enclosure.
- Accelerate data access with performance up to 14 GB/s sequential read, 12 GB/s sequential write and 17,680 IOPS.
- Specially-tuned modular chassis maximises drive performance and longevity by protecting against vibrational and acoustic interference, heat and power irregularities.
- Engineered and manufactured by Seagate for tightly-integrated, highly-compatible and predictable performance.
- Capacity, reliability and speed - perfect for any macro-edge or core data centre.
Spécifications techniques
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Controllers | |
| Controller Type | Serial Attached SCSI (SAS) |
| RAID Supported | Yes |
| I/O Expansions | |
| Number of Total Expansion Bays | 106 |
| Hot Swappable Bays | Yes |
| Interfaces/Ports | |
| Host Interface | 12Gb/s SAS |
| Number of SAS Ports (External) | 4 |
| Power Description | |
| Redundant Power Supply | Yes |
| Maximum Power Supply Wattage | 2 kW |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Restriction of Hazardous Substances (RoHS) | |
| Waste Electrical and Electronic Equipment Directive (WEEE) | |
| Physical Characteristics | |
| Weight (Approximate) | 131.50 kg |
| Rack Height | 4U |
| Height | 6.94" (176.40 mm) |
| Width | 17.36" (441 mm) |
| Depth | 44.84" (1139 mm) |
| Storage | |
| Hard Drive Interface | Serial Attached SCSI (SAS) |
| Total Hard Drive Capacity Supported | 2170.88 TB |
| Total Hard Drive Capacity Installed | 1955.84 TB |
| Number of Hard Drives Supported | 106 |
| Number of Hard Drives Installed | 106 |
| General Information | |
| Product Type | DAS Storage System |
| Manufacturer Part Number | R4106I190800001 |
| Manufacturer Website Address | http://www.seagate.com |
| Manufacturer | Seagate Technology |
| Product Name | Exos CORVAULT DAS Storage System |
| Brand Name | Seagate |
| Management & Protocols | |
| Protocols | SSL |
| SSH | |
| SNMP | |
| HTTP | |
| HTTPS | |
| SMTP |
