À propos du produit
Panneaux de dérivation de service extrêmement fiables conçus pour les produits APC InfraStruXure® Type A, Smart-UPS et Symmetra UPS.
Spécifications techniques
| Warranty | |
| Additional Warranty Information | 2 years (parts only) |
| Technical Information | |
| Protection Type | Overload |
| Receptacles | 1 x Hard Wire 4-wire (2PH+N+G) |
| 1 x Hard Wire 3-wire (2PH + G) | |
| Plug/Connector Type | Hard Wire 4-wire |
| Hard Wire 3-wire | |
| General Information | |
| Product Type | Bypass Switch |
| Manufacturer Part Number | SBP16KRMP4U-HW |
| Manufacturer Website Address | http://www.schneider-electric.com |
| Manufacturer | Schneider Electric SA |
| Product Name | 19" Rack-Mountable 100A Bypass Panel |
| Brand Name | APC by Schneider Electric |
| Power Description | |
| Input Voltage | 208 V AC |
| Output Voltage | 120 V AC |
| 208 V AC | |
| 200 V AC | |
| Current | 100 A |
| Load Capacity (VA) | 20 kW |
| Physical Characteristics | |
| Weight (Approximate) | 51.10 lb (23178.57 g) |
| Form Factor | Rack-mountable |
| Rack Height | 4U |
| Height | 7.01" (178 mm) |
| Width | 17.01" (432 mm) |
| Depth | 26.50" (673 mm) |
| Product Color | Black |
| Color Family | Black |
| Mounting Location | Front |
| Mounting Preference | Lower |
| Miscellaneous | |
| Package Contents | |
| Certifications & Standards | CSA|GOST |
| Environmentally Friendly | Yes |
| Mercury Free | Yes |
| For Country/Region | United States |
| Product Take Back Program | No |
| RoHS Exemption Information | https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=SBP16KRMP4U-HW_ROHS_DECLARATION&p_FileName=SBP16KRMP4U-HWKIT_ROHS_DECLARATION_US.pdf |
| REACH Declaration URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=764480&lang=en-us |
| EU RoHS Declaration URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=764480&lang=en-us |
| REACH free of SVHC | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
