À propos du produit
Designed for use with Power over Ethernet (PoE) devices, the SD4P1 switch provides up to 15.4W of power to 802.af PoE compatible devices connected to the switch's PoE ports. The Switch allows these devices to draw power from the switch and remove the need for a power adapter. Some devices that may have support for 802.3af are Wireless Access Points, IP Phones and IP Cameras. The Switch's ports automatically negotiate between 10BASE-T and 100BASE-TX network speeds, as well as between full and half duplex modes, so any port can connect to a Fast Ethernet or Ethernet network. The ports also support Auto MDIX, allowing the automatic detection of a straight through or cross-over cable, this feature reduces support problems commonly caused by incorrect cable usage.
- 5 Port 10/100 Desktop Switch with 4 x 10/100 PoE 802.3af and 1 x 10/100 uplink
- Standard IEEE802.3af support
- Wall and deskmount mounting
- Metal Chassis Construction
- Total PoE power budget: 60W
- Supports networking standards IEEE 802.3i, 802.3x, 802.3af
Spécifications techniques
| Management & Protocols | |
| Manageable | No |
| Network & Communication | |
| Layer Supported | 2 |
| Miscellaneous | |
| Package Contents |
|
| Country of Origin | China |
| Power Description | |
| Power Source | Power Supply |
| Redundant Power Supply Supported | No |
| Media & Performance | |
| Network Technology | 10/100Base-TX |
| Ethernet Technology | Fast Ethernet |
| Media Type Supported | Twisted Pair |
| Interfaces/Ports | |
| Modular | No |
| Uplink Port | Yes |
| Stack Port | No |
| Total Number of Network Ports | 5 |
| Port/Expansion Slot Details | 1 x Fast Ethernet Uplink |
| 4 x Fast Ethernet Network | |
| General Information | |
| Product Type | Ethernet Switch |
| Manufacturer Part Number | SD4P1 |
| Manufacturer Website Address | http://www.amermounts.com |
| Packaged Quantity | 1 |
| Manufacturer | Amer Networks, Inc |
| Product Model | SD4P1 |
| Product Name | 5 Port 10/100 Desktop Switch with 4 x 10/100 PoE 802.3af |
| Brand Name | Amer |
| Physical Characteristics | |
| Weight (Approximate) | 9.60 oz (272.155422 g) |
| Form Factor | Desktop |
| Wall Mountable | |
| Under Table | |
| Length | 4.65" (118.11 mm) |
| Height | 1.10" (27.94 mm) |
| Width | 3.35" (85.09 mm) |
| Product Color | Blue |
