- Ports: Provide 4*10/100Mbps PoE ports and 1 *100Mbps Uplink
- PoE Standard: IEEE802.3af/at Power over Ethernet (PoE) Compliant
- Total Power: Total power budget of 65W and 30W for all singe PoE ports
- Self-adaption: RJ45 port supports 10/100Mbps Auto MDI/MDIX
- Extend Mode: Extend PoE up to 250m on one single cable
- Wide Application: Designed for WiFi AP and IP Security camera.VoIP etc
- Surge Protection: Protect the device from lighting surges and others electrical hazards
- Considerate Design: Exquisite compact size with fanless design
- Easy to use: Plug and play, No configuration required
Versatile PoE Port
Featuring 4* 10/100Mbps PoE ports which support IEEE802.3af/at standard and 1* 100Mbps Uplink ports. The PoE switch provides a maximum power budget of 65W and 30W for single PoE ports
Flexible Extend Mode
With the extend mode, the PoE Switch is able to offer more flexible choices for long range transmission, extending the distance up to 250m
Surge Protection Design
Reaching 6KV surge protection, the PoE ports owns the capacity to keep the PoE Switch from lightning strikes and other electrical surges, offering reliable performance even in some harsh environments.
- Featuring Fast Ethernet ports to speed up the transfer rate up to 100mb/sec of large files and digital assets across your network
- With leading Layer 2 support, experience enhanced convenience, secure business operations, and a borderless network experience
- The unmanaged switch provides a quick, easy and cost-saving way to add wired networking to your home, office or small business; no intervention needed
- Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
- Built-in power supply to ensure all components are being supplied with accurate voltage
- Create your own LAN and connect your PC, laptop, printer and other peripherals with the help of 5 ports
- Cascade to other network devices through the uplink port to expand your local area network
Spécifications techniques
| Management & Protocols | |
| Manageable | No |
| Technical Information | |
| Features | Fanless |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Media & Performance | |
| Network Technology | 10/100Base-T |
| Ethernet Technology | Fast Ethernet |
| Media Type Supported | Twisted Pair |
| Physical Characteristics | |
| Weight (Approximate) | 1.87 lb (850 g) |
| Height | 1.10" (28 mm) |
| Width | 4.61" (117 mm) |
| Depth | 3.35" (85 mm) |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Uplink Port | Yes |
| Total Number of Network Ports | 5 |
| Port/Expansion Slot Details | 4 x Fast Ethernet PoE |
| 1 x Fast Ethernet Uplink | |
| Network & Communication | |
| Layer Supported | 2 |
| Networking Standards | IEEE 802.3at |
| IEEE 802.3u | |
| IEEE 802.3af | |
| IEEE 802.3x | |
| IEEE 802.3i | |
| General Information | |
| Product Type | Ethernet Switch |
| Manufacturer Part Number | SD4P1-60 |
| Manufacturer Website Address | http://www.amermounts.com |
| Manufacturer | Amer Networks, Inc |
| Product Model | SD4P1-60 |
| Product Name | SD4P1-60 Ethernet Switch |
| Brand Name | Amer |
| Power Description | |
| Input Voltage | 120 V AC |
| 230 V AC | |
| Power Source | Power Supply |
| Frequency | 60 Hz |
| 50 Hz | |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 65 W |
