À propos du produit
- 1.80 kW load capacity - backup power for your valuable electronics
- Prevent critical data loss by staying powered during a blackout with up to 1.80 kW load capacity
- 2 kVA load capacity provides sufficient backup during power failures
- Keep your sensitive devices powered with a backup of up to 10.38 minute at full load
Spécifications techniques
| Display & Graphics | |
| Display | LCD |
| Interfaces/Ports | |
| USB | Yes |
| Serial Port | Yes |
| EPO Port | Yes |
| Management | |
| Alarm | Low Battery |
| On Battery | |
| Overload | |
| Environmental Conditions | |
| Maximum Operating Temperature | 104°F (40°C) |
| Maximum Operating Elevation | 9842.52 ft (3000000 mm) |
| Maximum Storage Elevation | 49212.60 ft (15000000 mm) |
| Sound Emission (A-Weighted) | 50 dB(A) |
| Battery Information | |
| Battery Life | 10 Year |
| Battery Chemistry | Lithium Ion (Li-Ion) |
| Battery Size | 48V |
| Backup/Run Time (Half Load) | 21 Minute |
| Backup/Run Time (Full Load) | 10.38 Minute |
| Typical Battery Recharge Time | 2 Hour |
| Miscellaneous | |
| Package Contents |
|
| Environmentally Friendly | Yes |
| Environmental Compliance | China Restriction of Hazardous Substances (China RoHS) |
| Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) | |
| Restriction of Hazardous Substances (RoHS) | |
| Waste Electrical and Electronic Equipment Directive (WEEE) | |
| Technical Information | |
| Application/Usage | Automation System |
| Building System | |
| Distribution Center | |
| Plug/Connector Type | NEMA 5-20P |
| Phase | Single Phase |
| Receptacle Type | NEMA 5-20R |
| Receptacle Detail | 6 x NEMA 5-20R |
| General Information | |
| Product Type | Double Conversion Online UPS |
| Manufacturer Part Number | SRVSL2KRARK |
| Manufacturer Website Address | http://www.schneider-electric.com |
| Packaged Quantity | 1 |
| Manufacturer | Schneider Electric SA |
| Product Name | Easy UPS On-Line Li-Ion SRVSL RT 2000VA 120V, with Rail Kit |
| Product Line | Easy UPS On-Line |
| Product Series | SRVSL RT |
| Brand Name | Schneider Electric |
| Physical Characteristics | |
| Weight (Approximate) | 36.60 lb (16600 g) |
| Form Factor | Rack-mountable |
| Rack Height | 2U |
| Height | 3.39" (86 mm) |
| Width | 17" (431.80 mm) |
| Depth | 20" (508 mm) |
| Product Color | Black |
| Silver | |
| Color Family | Dual Color |
| Power Description | |
| Input Voltage | 120 V AC |
| Output Voltage | 110 V AC |
| 120 V AC | |
| 115 V AC | |
| Surge Energy Rating | 220 J |
| Waveform Type | Sine Wave |
| Input Voltage Range | 55 V AC - 150 V AC |
| 80 V AC - 150 V AC | |
| Output Frequency | 60 Hz |
| Input Frequency | 70 Hz |
| Load Capacity (VA) | 2 kVA |
| Load Capacity (Watt) | 1.80 kW |
| Output Power Factor | 0.9 |
