À propos du produit
- 4× 10 Gbps PoE++ RJ45 Ports
- 2× 10 Gbps SFP+ Slots
- 200 W Total PoE Budget with up to 60 W per Port
- Centralized Management
- Omada App
- Zero-Touch Provisioning
- Ethernet Ring Protection Switching
- Static Routing
- Optimize the performance of business networks with 10 Gigabit Ethernet connectivity
- Layer 2 switch provides a complete lineup of features including IGMP snooping, port mirroring, and spanning tree
- With leading Layer 2 support, experience enhanced convenience, secure business operations, and a borderless network experience
- Management capability provides control over setup and configuration of your network
- Built-in power supply to ensure all components are being supplied with accurate voltage
- Create your own LAN and connect your PC, laptop, printer and other peripherals with the help of 4 ports
Spécifications techniques
| Management & Protocols | |
| Manageable | Yes |
| Technical Information | |
| Features | Zero-Touch Provisioning (ZTP) |
| I/O Expansions | |
| Expansion Slot Type | SFP+ |
| Number of SFP+ Slots | 2 |
| Total Number of Expansion Slots | 2 |
| Miscellaneous | |
| Application/Usage | Wireless Access Point |
| Network | |
| Package Contents |
|
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Modular | Yes |
| Total Number of Network Ports | 4 |
| Port/Expansion Slot Details | 2 x 10 Gigabit Ethernet Expansion Slot |
| 4 x 10 Gigabit Ethernet PoE++ | |
| Media & Performance | |
| Network Technology | 10GBase-X |
| 10GBase-T | |
| Ethernet Technology | 10 Gigabit Ethernet |
| Media Type Supported | Twisted Pair |
| Optical Fiber | |
| Physical Characteristics | |
| Form Factor | Rack-mountable |
| Desktop | |
| Height | 1.70" (43.18 mm) |
| Width | 11.60" (294.64 mm) |
| Depth | 7.10" (180.34 mm) |
| General Information | |
| Product Type | Ethernet Switch |
| Manufacturer Part Number | SX3206HPP |
| Manufacturer Website Address | http://www.tp-link.com |
| Manufacturer | TP-LINK Technologies Co., Ltd |
| Product Model | SX3206HPP |
| Product Name | Omada 6-Port 10GE L2+ Managed Switch with 4-Port PoE++ |
| Product Line | Omada |
| Brand Name | TP-Link |
| Power Description | |
| Input Voltage | 120 V AC |
| 230 V AC | |
| Power Source | Power Supply |
| Frequency | 60 Hz |
| 50 Hz | |
| Power Consumption | 244.90 W |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 200 W |
| Network & Communication | |
| Layer Supported | 2 |
| Networking Standards | IEEE 802.3at |
| IEEE 802.1p | |
| IEEE 802.3x | |
| IEEE 802.3ah | |
| IEEE 802.3af | |
| IEEE 802.3ab | |
| IEEE 802.1x | |
| IEEE 802.1Q |
