À propos du produit
Symmetra LX est une plateforme d'onduleur modulaire, évolutive et redondante, conçue pour répondre aux besoins critiques en termes de disponibilité. Le Symmetra PXR à autonomie étendue dispose de 9 modules de batterie, soit 4 de plus que le Symmetra LX. Avec une extension jusqu'à 13 batteries (vendues séparément), vous bénéficiez d'une autonomie étendue selon vos besoins. Un abonnement d'un an à la carte de gestion réseau sécurisée est inclus. Garantie standard : 5 ans de réparation ou de remplacement.
Spécifications techniques
| Interfaces/Ports | |
| Modular Slots | 1 x SmartSlot |
| Warranty | |
| Additional Warranty Information | 2 years repair or replace |
| Environmental Conditions | |
| Thermal Dissipation | 4995 BTU/h |
| Maximum Operating Temperature | 104°F (40°C) |
| Battery Information | |
| Battery Chemistry | Lead Acid |
| Backup/Run Time (Half Load) | 1.23 Hour |
| Backup/Run Time (Full Load) | 33.50 Minute |
| Battery Characteristics | Spill-proof/Maintenance-free |
| Typical Battery Recharge Time | 7.50 Hour |
| Management | |
| Bypass Switch | Manual |
| External (Optional) | |
| Automatic | |
| Emergency Power OFF | Yes |
| Network Management | SNMP Manageable |
| Technical Information | |
| Overload Protection | Yes |
| Plug/Connector Type | Hard Wire 4-wire |
| Receptacle Type | Hard Wire 4-wire (2PH+N+G) |
| Number of Battery & Surge Outlets | 1 |
| Receptacle Detail | 1 x Hard Wire 4-wire (2PH+N+G) |
| Power Description | |
| Input Voltage | 208 V AC |
| Output Voltage | 120 V AC |
| 208 V AC | |
| Input Current | 75 A |
| Waveform Type | Sine Wave |
| Load Capacity (VA) | 16 kVA |
| General Information | |
| Product Type | Double Conversion Online UPS |
| Manufacturer Part Number | SYA16K16PXR |
| Manufacturer Website Address | http://www.schneider-electric.com |
| Manufacturer | Schneider Electric SA |
| Product Name | Symmetra LX 16kVA Scalable to 16kVA N+1 Ext. Run Tower UPS |
| Product Line | Symmetra |
| Product Series | LX |
| Brand Name | APC by Schneider Electric |
| Physical Characteristics | |
| Weight (Approximate) | 1110.34 lb (503641.75 g) |
| Form Factor | Tower |
| Rack Height | 19U |
| Height | 59.69" (1516 mm) |
| Width | 19.02" (483 mm) |
| Depth | 28.58" (726 mm) |
| Product Color | Silver |
| Black | |
| Color Family | Dual Color |
| Mounting Location | Front |
| Mounting Preference | No Preference |
| Miscellaneous | |
| Additional Information |
|
| Package Contents | |
| Certifications & Standards | CSA |
| Country of Origin | Philippines |
| Environmentally Friendly | Yes |
| Mercury Free | Yes |
| For Country/Region | United States |
| Optimized Energy Efficiency | Yes |
| Product Take Back Program | Yes |
| RoHS Exemption Information | https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=SYA16K16PXR_ROHS_DECLARATION&p_FileName=SYA16K16PXRKIT_ROHS_DECLARATION_US.pdf |
| REACH Declaration URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=61763590&lang=en-us |
| EU RoHS Declaration URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=61763590&lang=en-us |
| REACH free of SVHC | No |
| California Proposition 65 Warning | WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
