À propos du produit
The TRENDnet 2-Pack 10GBASE-LR SFP+ Multi-Mode LC Module is an MSA-compliant SFP+ port converter designed for long-distance (300m) fiber-optic to SFP+ connections on standard networking equipment. Includes an LC duplex connector for fiber-optic connections—ideal for large-scale industrial and corporate networks with multi-property networking requirements.
Hot-pluggable, supports speeds up to 10.5Gbps. Compatible with multi-mode 850nm transmissions. Additional DDM support provides administrators with critical device information, including send/transmit power, temperature and voltage info.
Package includes 2x SFP+ modules.
TEG-10GBSR/2 Specs and Features
- Standards
- IEEE 802.3ae
- 10GBASE-SR
- Device Interface
- 10Gbps SFP+ MSA Compliant
- LC duplex connector
- Data Transfer Rate
- 8.5-10.5Gbps
- Wavelength
- 850nm
- Optical Output Power
- -1 ~ -7.5dBm
- Distance
- 400m (OM4)
- 300m (OM3)
- 82m (OM2)
- 33m (OM1)
- Special Features
- Hot pluggable
- Metal enclosure
- DDM support
- Sensitivity
- -14 dBm
- Power
- Max. consumption: 439mW
- Operating Temperature
- 0 – 70 °C (32 - 158 °F)
- Operating Humidity
- Max. 95% non-condensing
- Dimensions
- 14.8 x 56.5 x 11.85mm (0.6 x 2.2 x 0.5 in) per unit
- 22g (0.7 oz.) per unit
- Certifications
- CE
- FCC
- Warranty
- Lifetime Manufacturer's Warranty
- What's Included
- 2 x TEG-10GBSR
Spécifications techniques
The TRENDnet 2-Pack 10GBASE-LR SFP+ Multi-Mode LC Module is an MSA-compliant SFP+ port converter designed for long-distance (300m) fiber-optic to SFP+ connections on standard networking equipment. Includes an LC duplex connector for fiber-optic connections—ideal for large-scale industrial and corporate networks with multi-property networking requirements.
Hot-pluggable, supports speeds up to 10.5Gbps. Compatible with multi-mode 850nm transmissions. Additional DDM support provides administrators with critical device information, including send/transmit power, temperature and voltage info.
Package includes 2x SFP+ modules.
TEG-10GBSR/2 Specs and Features
- Standards
- IEEE 802.3ae
- 10GBASE-SR
- Device Interface
- 10Gbps SFP+ MSA Compliant
- LC duplex connector
- Data Transfer Rate
- 8.5-10.5Gbps
- Wavelength
- 850nm
- Optical Output Power
- -1 ~ -7.5dBm
- Distance
- 400m (OM4)
- 300m (OM3)
- 82m (OM2)
- 33m (OM1)
- Special Features
- Hot pluggable
- Metal enclosure
- DDM support
- Sensitivity
- -14 dBm
- Power
- Max. consumption: 439mW
- Operating Temperature
- 0 – 70 °C (32 - 158 °F)
- Operating Humidity
- Max. 95% non-condensing
- Dimensions
- 14.8 x 56.5 x 11.85mm (0.6 x 2.2 x 0.5 in) per unit
- 22g (0.7 oz.) per unit
- Certifications
- CE
- FCC
- Warranty
- Lifetime Manufacturer's Warranty
- What's Included
- 2 x TEG-10GBSR
