À propos du produit
- 5× 10 Mbps/100 Mbps/1 Gbps/2.5 Gbps RJ45 ports
- With four PoE++ ports, transfers data and power on one single cable
- Works with IEEE 802.3af/at/bt type3 compliant PDs
- 802.1p/DSCP QoS enable smooth latency-sensitive traffic
- Supports PoE Power up to 60 W for each PoE++ port
- Supports PoE Power up to 123 W for all PoE ports*
- PoE Auto Recovery guarantees stable operation of PoE devices by automatically rebooting the dropped or unresponsive PD devices
- Plug and Play, no configuration and installation required
Spécifications techniques
| Management & Protocols | |
| Manageable | No |
| Technical Information | |
| Features | Fanless |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Total Number of Network Ports | 5.0 |
| Port/Expansion Slot Details | 5 x 2.5 Gigabit Ethernet PoE++ |
| Media & Performance | |
| Network Technology | 2.5GBase-T |
| Ethernet Technology | 2.5 Gigabit Ethernet |
| Media Type Supported | Twisted Pair |
| Miscellaneous | |
| Application/Usage | Network |
| Package Contents |
|
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Power Description | |
| Input Voltage | 53.5 V DC |
| Power Source | Power Adapter |
| Power Consumption | 143.37 W |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 123 W |
| General Information | |
| Product Type | Ethernet Switch |
| Manufacturer Part Number | TLSG105PPM2 |
| Manufacturer Website Address | http://www.tp-link.com |
| Manufacturer | TP-LINK Technologies Co., Ltd |
| Product Model | TL-SG105PP-M2 |
| Product Name | 5-Port 2.5G Desktop Switch with 4-Port PoE++ |
| Brand Name | TP-Link |
| Network & Communication | |
| Layer Supported | 2 |
| Networking Standards | IEEE 802.3x |
| IEEE802.3af | |
| IEEE 802.3bt | |
| IEEE 802.3at | |
| IEEE 802.3ab | |
| IEEE 802.3 | |
| IEEE 802.1p | |
| Physical Characteristics | |
| Form Factor | Wall Mountable |
| Desktop | |
| Height | 1.02" (26 mm) |
| Width | 8.23" (209 mm) |
| Depth | 4.96" (126 mm) |
| Product Color | Black |
| Color Family | Black |
| Product Material | Steel |
