À propos du produit
Our On-Line UPS is designed to handle demanding power conditions, where uptime and efficiency is critical. Providing double-conversion online power protection technology and advanced management features for server rooms, network closets, edge computing and other high demand environments, this UPS is suitable for verticals ranging from healthcare, retail, finance to manufacturing and even industrial automation.
- Prevent critical data loss by staying powered during a blackout with up to 1.30 kW load capacity
- 1.50 kVA load capacity provides sufficient backup during power failures
- Keep your sensitive devices powered with a backup of up to 2.70 minute at full load
Spécifications techniques
| Controls/Indicators | |
| Status Indicators | LCD Display:
|
| Display & Graphics | |
| Display | LCD |
| Warranty | |
| Additional Warranty Information | 3 Year (1 Year Battery) |
| Environmental Conditions | |
| Sound Emission | 50 dB |
| Maximum Operating Temperature | 104°F (40°C) |
| Interfaces/Ports | |
| USB | Yes |
| EPO Port | Yes |
| Management | |
| Network Management | SNMP |
| Smart RS-232/USB | |
| Alarm | Battery Mode |
| Fault | |
| Low Battery | |
| Overload | |
| Miscellaneous | |
| Package Contents |
|
| Country of Origin | Taiwan |
| Environmentally Friendly | Yes |
| TAA Compliant | Yes |
| Energy Star | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) | |
| General Information | |
| Product Type | Double Conversion Online UPS |
| Manufacturer Part Number | UPS2URM1500DC-NC-1N |
| Manufacturer Website Address | http://www.v7-world.com |
| Manufacturer | V7 |
| Product Model | UPS2URM1500DC-NC-1N |
| Product Name | On-Line UPS2URM1500DC-NC-1N 1500VA Rack-mountable UPS |
| Product Series | On-Line |
| Brand Name | V7 |
| Physical Characteristics | |
| Weight (Approximate) | 34.83 lb (15800 g) |
| Form Factor | Rack-mountable |
| Length | 16.14" (410 mm) |
| Rack Height | 2U |
| Height | 3.39" (86.20 mm) |
| Width | 17.24" (438 mm) |
| Product Color | Black |
| Color Family | Black |
| Battery Information | |
| Battery Chemistry | Lead Acid |
| Battery Size | 12V |
| Battery Capacity | 9000 mAh |
| Number of Batteries | 3 |
| Backup/Run Time (Half Load) | 9.80 Minute |
| Backup/Run Time (Full Load) | 2.70 Minute |
| Battery Characteristics | Sealed |
| DC System Voltage | 41.1 V DC |
| Typical Battery Recharge Time | 3 Hour |
| Technical Information | |
| Application/Usage | Server Room |
| Industrial Automation System | |
| Finance | |
| Edge Computing | |
| Healthcare | |
| Manufacturing | |
| Network Closet | |
| Retail | |
| Dataline Protection | RJ-11/RJ-45 |
| Overload Protection | Yes |
| Plug/Connector Type | NEMA 5-15P |
| Phase | Single Phase |
| Receptacle Type | NEMA 5-15R |
| Transfer Time | 0 ns |
| Receptacle Detail | 8 x NEMA 5-15R |
| Power Description | |
| Input Voltage | 120 V AC |
| Output Voltage | 110 V AC |
| 127 V AC | |
| 120 V AC | |
| 100 V AC | |
| 115 V AC | |
| Surge Energy Rating | 720 J |
| Waveform Type | Pure Sine Wave |
| Input Voltage Range | 55 V AC - 150 V AC |
| 80 V AC - 150 V AC | |
| Output Frequency | 60 Hz |
| Input Frequency | 70 Hz |
| Load Capacity (VA) | 1.50 kVA |
| Load Capacity (Watt) | 1.30 kW |
| Input Power Factor | 0.99 |
| Output Power Factor | 0.96 |
