À propos du produit
Our single phase, double conversion online UPS is designed to handle demanding power conditions, where uptime and efficiency is critical. Providing double-conversion online power protection technology and advanced management features for server rooms, network closets, edge computing and other high demand environments, this UPS is suitable for verticals ranging from healthcare, retail, finance to manufacturing and even industrial automation.
- Prevent critical data loss by staying powered during a blackout with up to 2.74 kW load capacity
- 3 kVA load capacity provides sufficient backup during power failures
- Up to 2.60 minute runtime on full load to preserve critical data from power shortage interruptions
Spécifications techniques
| Controls/Indicators | |
| Status Indicators | LCD Display:
|
| Display & Graphics | |
| Display | LCD |
| Warranty | |
| Additional Warranty Information | 3 Year (1 Year Battery) |
| Environmental Conditions | |
| Maximum Operating Temperature | 104°F (40°C) |
| Sound Emission (A-Weighted) | 50 dB(A) |
| Interfaces/Ports | |
| USB | Yes |
| EPO Port | Yes |
| Management | |
| Network Management | Smart RS-232/USB |
| SNMP | |
| Alarm | Battery Mode |
| Fault | |
| Low Battery | |
| Overload | |
| Miscellaneous | |
| Package Contents |
|
| Country of Origin | Taiwan |
| Environmentally Friendly | Yes |
| TAA Compliant | Yes |
| Energy Star | Yes |
| Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Restriction of Hazardous Substances (RoHS) | |
| General Information | |
| Product Type | Double Conversion Online UPS |
| Manufacturer Part Number | UPS2URM3000DC-NC-1N |
| Manufacturer Website Address | http://www.v7-world.com |
| Manufacturer | V7 |
| Product Model | UPS2URM3000DC-NC-1N |
| Product Name | On-Line UPS2URM3000DC-NC-1N 3000VA Rack-mountable UPS |
| Product Series | On-Line |
| Brand Name | V7 |
| Physical Characteristics | |
| Weight (Approximate) | 59.96 lb (27197.40 g) |
| Form Factor | Rack-mountable |
| Length | 24.80" (630 mm) |
| Rack Height | 2U |
| Height | 3.39" (86.20 mm) |
| Width | 17.24" (438 mm) |
| Product Color | Black |
| Color Family | Black |
| Battery Information | |
| Battery Chemistry | Lead Acid |
| Battery Size | 12V |
| Battery Capacity | 9000 mAh |
| Number of Batteries | 6 |
| Backup/Run Time (Half Load) | 10 Minute |
| Backup/Run Time (Full Load) | 2.60 Minute |
| Battery Characteristics | Sealed |
| DC System Voltage | 82.1 V DC |
| Typical Battery Recharge Time | 3 Hour |
| Power Description | |
| Input Voltage | 120 V AC |
| Output Voltage | 120 V AC |
| 127 V AC | |
| 115 V AC | |
| 100 V AC | |
| 110 V AC | |
| Surge Energy Rating | 720 J |
| Waveform Type | Pure Sine Wave |
| Input Voltage Range | 55 V AC - 150 V AC |
| 80 V AC - 150 V AC | |
| Output Frequency | 60 Hz |
| Input Frequency | 70 Hz |
| Load Capacity (VA) | 3 kVA |
| Load Capacity (Watt) | 2.74 kW |
| Input Power Factor | 0.99 |
| Output Power Factor | 0.9 |
| Technical Information | |
| Application/Usage | Finance |
| Healthcare | |
| Industrial Automation System | |
| Manufacturing | |
| Network Closet | |
| Retail | |
| Server Room | |
| Edge Computing | |
| Dataline Protection | RJ-11/RJ-45 |
| Overload Protection | Yes |
| Plug/Connector Type | NEMA L5-30P |
| Phase | Single Phase |
| Receptacle Type | NEMA 5-15/20R |
| NEMA L5-30R | |
| Transfer Time | 0 ns |
| Receptacle Detail | 6 x NEMA 5-15/20R |
| 1 x NEMA L5-30R |
