À propos du produit
Plugable's USB-C Mini Dock enables you to connect an external monitor, USB peripheral and USB-C power adapter to a USB Type-C or Thunderbolt 3 supported system. The compact size allows for ultra portability and removes the need to carry multiple dongles that could occupy other valuable ports\n\n Performance\nThe Plugable USB-C Mini Dock leverges the USB-C DisplayPort Alt Mode and USB Power Delivery technologies to support an external monitor and Power Delivery functions. It offers a USB 3.0 Type-A port that supports data transfer speeds up to 5Gbps. The Mini Dock is entirely USB bus powered and does not require a power supply to work. Please note: disconnecting the system's USB power adapter when plugged into the Mini Dock will disconnect the connected monitor and USB device and they should autmatically reconnect\nThe HDMI 1.4 port on the Mini Dock can support resolutions up to 3840x2160@30Hz and 1080p resolutions at 60Hz\nCharge your system's battery using its USB-C power adapter while conencted to the USB-C 3
0 Power Delivery input port (5-20v @ 3A)\n\n Compatibility\nCompatible with Windows, macOS, and Linux systems with a USB-C port that supports DisplayPort Alternate Mode, USB Power Delivery or Thunderbolt 3. Our adapter has been tested on the 2016 / 2017 MacBook Pro 13 / 15 , HP Spectre x360 13 (13-ac013dx).\nNot compatible with USB Type-A systems even when used with USB Type-A to USB Type-C adapters.\nThe host system and connected monitor must support the desired resolution. The host system must also support Power Delivery over USB-C in order for charging functions to work\n\n In the Box\nPlugable USB-C Mini Dock\nQuick Start Guide More from the ManufacturerUSB 3.0 port supports up to 5Gbps transfer rateHDMI port supports up to 4K @ 30Hz resolutionPasses through USB-C PD charging (5-20V @ 3A)Compatible with Windows, Mac, and Linux
Spécifications techniques
| Power Description | |
| Maximum Power Supply Wattage | 130 W |
| Software | |
| Operating System Supported | Linux |
| macOS | |
| Windows | |
| Technical Information | |
| Device Supported | Notebook/Tablet PC/Desktop PC |
| Connectivity Technology | Wired |
| Supported Resolutions | 3840 x 2160 |
| Screen Mode Supported | 4K |
| General Information | |
| Product Type | Docking Station |
| Manufacturer Part Number | USBC-MD101 |
| Manufacturer Website Address | http://www.plugable.com |
| Manufacturer | Plugable Technologies |
| Product Model | USBC-MD101 |
| Product Name | USB C Mini Dock with HDMI, USB 3.0 and Pass-Through Charging |
| Product Line | Mini Dock |
| Brand Name | Plugable |
| Interfaces/Ports | |
| Host Interface | USB 3.1 |
| HDMI | Yes |
| Number of HDMI Ports | 1 |
| Total Number of USB Ports | 2 |
| Number of USB 3.0 Ports | 2 |
| Thunderbolt | Yes |
| USB Type-C | Yes |
| USB Type-C Detail | 1 x USB 3.0 Type-C |
| Number of USB Type-A Ports | 1 |
| USB Type-A | Yes |
| Miscellaneous | |
| Additional Information |
|
| Package Contents |
|
| Compatibility |
|
| Country of Origin | China |
| Brand Compatibility | Apple |
| Asus | |
| Dell | |
| HP | |
| Lenovo | |
| Microsoft |
