À propos du produit
UTC-320 is the multi-purpose all-in-one computing system which equipped with wide format, touch based LCD panel. It is easy to integrate key peripherals and display systems for diversified self-service and interactive signage deploy in different application areas. With the emovable frame , the system also could fulfill industries or control system applications with panel mounting design. UTC series touch panel computers are the best investments to enhance user satisfaction, further brand equity, and maximize business profits.
- Digital Signage Display delivers a highly realistic sound and immersive visual experience thanks to the high pixel density that shows even the most subtle details
- 21.5" (546.10 mm) - Perfect for showing special recordings, educational messages, pennants and engaging video files in 1920 x 1080 resolution
- Experience luminescent visual images with LCD display
- Features full 1920 x 1080 HD resolution enabling sharp and clear images
- Features 1920 x 1080 resolution and 1080p scan format for producing sharp and bright images
- LED backlight technology provides for industry-leading low power consumption and less hazardous materials
- Experience responsive performance, power and adaptability with Intel Celeron 2 GHz processor
Spécifications techniques
| Memory | |
| Standard Memory | 4 GB |
| Power Description | |
| Input Voltage | 12 V DC |
| Network & Communication | |
| Ethernet | Yes |
| Wireless LAN | Yes |
| Video | |
| Brightness | 250 cd/m² |
| Scan Format | 1080p |
| Miscellaneous | |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Processor & Chipset | |
| Processor Speed | 2 GHz |
| Processor Type | Celeron |
| Processor Core | Quad-core (4 Core) |
| Interfaces/Ports | |
| USB | Yes |
| HDMI | Yes |
| Number of USB 2.0 Ports | 5 |
| Number of USB 3.0 Ports | 1 |
| Serial | Yes |
| Display & Graphics | |
| Pixel Pitch | 9.76 mil (0.25 mm) |
| Display Resolution | 1920 x 1080 |
| Screen Size | 21.5" (546.10 mm) |
| Touchscreen | Yes |
| Display Screen Type | LCD |
| Backlight Technology | LED |
| Physical Characteristics | |
| Weight (Approximate) | 12.79 lb (5800 g) |
| Height | 12.44" (316 mm) |
| Width | 19.88" (505 mm) |
| Depth | 1.81" (45.90 mm) |
| VESA Mount Standard | 100 x 100 |
| Product Color | Black |
| General Information | |
| Product Type | Digital Signage Display |
| Manufacturer Part Number | UTC-320DP-ATB0E |
| Manufacturer Website Address | http://www.advantech.com |
| Manufacturer | Advantech Co., Ltd |
| Product Model | UTC-320D |
| Product Name | UTC-320D 21.5" Ubiquitous Touch Computer with Intel Celeron J1900 Processor |
| Product Line | Ubiquitous |
| Product Series | UTC |
| Brand Name | Advantech |
