About the product
COOLMAX M-500B power supply is simple with more connectors for users. It has 5 SATA and 5 Peripheral connectors ready to power all your devices. And for users with high end CPUs and video cards, it has 8 pin Xeon connector and PCI-E connector ready. With a fast cooling system at its quietest intensity level possible and its efficient air ventilation design, the M-500B is able to run the 120mm fan at slower speeds, providing a quieter, yet cooler environment.
- Quiet Performance
- Silent 120mm Cooling Fan
- High energy efficiency
- 115V, 230 switchable power supply
- Compatible with ATX 12V 2.3/ EPS 12V
Technical Specifications
| Miscellaneous | |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Technical Information | |
| Protection Type | Under Voltage |
| Over Voltage | |
| Number of Fans | 1 |
| Specification Compliance | ATX12V/EPS12V |
| Interfaces/Ports | |
| Receptacles | 5 x 4-pin Peripheral Device |
| 5 x 5-pin Serial ATA | |
| 1 x PCI-E | |
| 1 x 8-pin EPS12V Motherboard | |
| 1 x 24-pin ATX Motherboard | |
| Physical Characteristics | |
| Weight (Approximate) | 1.59 kg |
| Height | 3.30" (83.82 mm) |
| Width | 5.90" (149.86 mm) |
| Depth | 5.60" (142.24 mm) |
| Product Color | Black |
| General Information | |
| Product Type | Power Supply |
| Manufacturer Part Number | 14622 |
| Manufacturer Website Address | http://www.coolmaxusa.com |
| Packaged Quantity | 6 |
| Manufacturer | Coolmax Technology, Inc |
| Product Model | M-500B |
| Product Name | 500W 120mm Fan ATX Power Supply M-500b |
| Brand Name | Coolmax |
| Power Description | |
| Input Voltage | 120 V AC |
| 230 V AC | |
| Output Power | 500 W |
| Output Voltage | 5 V DC |
| -12 V DC | |
| 12 V DC | |
| 3.3 V DC | |
| Input Voltage Range | 100 V AC - 264 V AC |
