About the product
Color made easy with HP SmartColor
- Confidently distribute jobs across your fleet with best-in-class color consistency from printer to printer.
- Get accurate colors over time, even as environmental conditions change, with the built-in spectrophotometer.
- Automatically detect when a color is out of gamut and get the closest visual match with PANTONE® emulation.
- Easily create color profiles in half the time , or use finished profiles from our cloud-based library.
- Run at top speed while producing richly saturated color, with the symmetrical 2xCMYK printhead configuration.
- Print an entire shift unattended or overnight with the largest media rolls and large ink supplies.
- Stay in control and maximize uptime with realtime fleet management and HP Smart Services.
- Reduce your media costs and avoid cockling when using lightweight transfer paper with the Drop & Dry system.
- Avoid reprints and media waste with 1200 dpi printheads and the Smart Nozzle Compensation system.Save 50% floor space with the first dye-sub printer with front media loading.
- Save 50% floor space with the first dye-sub printer with front media loading.
- Optimize your workflows by sharing the resources of the printer with Ethernet connectivity
- Offers professional quality documents that can be printed either in color or monochrome
- Designed for dye-sublimation printing to deliver outstanding print quality on long print runs, day-after-day
Technical Specifications
| Network & Communication | |
| Ethernet | Yes |
| Warranty | |
| Additional Warranty Information | Hardware warranty |
| Physical Characteristics | |
| Weight (Approximate) | 226 kg |
| Height | 55.91" (1420 mm) |
| Width | 100.79" (2560 mm) |
| Depth | 27.95" (710 mm) |
| Media Types & Handling | |
| Media Size | 23" (584.20 mm) to 64" (1625.60 mm) Width - Roll Paper |
| Media Type | Sublimation Film |
| Sublimation Polyester Fabric | |
| Roll Paper | |
| Sublimation Transfer Paper | |
| Technical Information | |
| Maximum Print Width | 64" |
| Number of Colors | 4 |
| Print Color Capability | Color |
| Maximum Color Print Speed (ft²/h) | 110 m²/h |
| Maximum Print Resolution (dpi) | 1200 x 1200 |
| General Information | |
| Product Type | Dye Sublimation Large Format Printer |
| Manufacturer Part Number | 2ET73A#B1K |
| Manufacturer Website Address | http://www.hp.com |
| Manufacturer | HP Inc. |
| Product Model | S500 |
| Product Name | Stitch S500 64-in Printer |
| Product Line | Stitch |
| Brand Name | HP |
| Miscellaneous | |
| Platform Supported | PC |
| Form Factor | Floor Standing Supported |
| Environmentally Friendly | Yes |
| Environmental Certification | Electronic Product Environmental Assessment Tool Bronze (EPEAT Bronze) |
| Energy Star | Yes |
| Environmental Compliance | Ukraine Restriction of Hazardous Substances (Ukraine RoHS) |
| Indian Restriction of Hazardous Substances | |
| Restriction of Hazardous Substances (RoHS) | |
| Waste Electrical and Electronic Equipment Directive (WEEE) | |
| Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) | |
| Korean Restriction of Hazardous Substances | |
| China Restriction of Hazardous Substances (China RoHS) | |
| Turkey Restriction of Hazardous Substances (Turkey RoHS) |
